Bose FreeSpace DS 100SE Service Manual

15
DISASSEMBLY PROCEDURES
8. Transformer Removal
8.1 Perform procedure 7.
8.2 Remove the four screws (5) that secure
the transformer (17) to the enclosure. Lift
out the transformer.
8.3 Make a note of the wiring configuration
and cut the wires that connect to the cross-
over PCB assembly (9) as close to the board
as possible.
9. Loudspeaker Mounting Bracket
Removal
9.1 Using a Phillips-head screwdriver, re-
move the four screws (13) that secure the
mounting bracket to the back of the loud-
speaker.
9.2 Slide the bracket (12) and rubber grom-
met (15) away from the speaker. Slide the
bracket off of the rubber grommet.
FreeSpace
®
DS 100F Flush-Mount
Loudspeaker
Note: Refer to Figure 5 for the following
procedures.
1. Grille Removal
1.1 Using a small tool, such as an awl,
carefully pry the grille (2) away from the front
baffle (8). Lift off the grille.
2. Logo Removal
2.1 Perform procedure 1.
2.2 Slide the retaining washer (3) off of the
logo's post. Lift the logo (1) off of the grille
(2).
3. Tweeter Driver Removal
3.1 Perform procedure 1.
3.2 Using a Phillips-head screwdriver, re-
move the four screws (24) that secure the
2.25" driver (4) to the baffle (8).
3.3 Lift out the driver. Disconnect the two
Faston connectors from the tweeter's termi-
nal strip.
4. Woofer Removal
4.1 Perform procedure 1.
4.2 Using a Phillips-head screwdriver, re-
move the four screws (18) that secure the
woofer (19) to the baffle (8).
4.3 Lift out the woofer. Disconnect the two
Faston connectors from the woofer's termi-
nal strip.

Bose FreeSpace DS 100SE Specifications

General

Certification	CE, IEC 529
Product color	White
Housing material	Acrylonitrile butadiene styrene (ABS)
Recommended usage	-
Suitable for outdoor use	Yes
Driver diameter	57 mm
Woofer diameter	133 mm
Number of drivers	2
Speaker enclosure	Ported
Speaker placement	Ceiling-mountable, Wall-mountable
Audio output channels	1.0 channels
Woofer diameter (imperial)	5.25 \
Impedance	8 Ω
Sensitivity	85 dB
Frequency range	75 - 18000 Hz
RMS rated power	- W
Package weight	7700 g
Transformer taps	12.5, 25, 50, 100 W

Weight and Dimensions

Depth	216 mm
Width	381 mm
Height	178 mm
Weight	6400 g
Depth (with stand)	280 mm
