Page #9 background image
9
MAIN PART LIST
FreeSpace
®
DS 100SE Loudspeaker (see Figure 3)
Item
Number
Description Bose
®
Part
Number
Vendor Part Number Qty.
Note
1 GRILLE CAP, BLACK
GRILLE CAP, WHITE
299560
299561
1467-7601+0
1467-7602+0
2
2 GRILLE, ASSY, BLACK
GRILLE, ASSY, WHITE
(Includes logo, screw, spring
and washers)
299558
299559
SVC-SCURL11+GRIL
SVC-SCURL12+GRIL
1
3 SCREW, M4x8 - 2950-4008+H000 4 4
4 DRIVER, 2.25W/GASKET 299562 SVC-8900-3850+0 2
5 SCREW, M4x16 - 2954-4016+H000 18 4
6 WOOFER, 5.25” W/GASKET 299563 SVC-8900-6800+0 1
7 SCREW, M4x16 - 2954-4016+H000 12 4
8 BAFFLE - 4155-2101+2 1 4
9 CROSSOVER PCB ASSY 299569 SVC-SCURL11+PCB 1 2
10 ENCLOSURE, BLACK
ENCLOSURE, WHITE
- 1467-7501+0
1467-7502+0
1 4
11 BRACKET ARM
(includes 4 mounting screws, 4
washers, 1 pivot screw)
BLACK
WHITE
315821-001S
315821-002S
4155-3421+0
4155-3422+0
1
12 SCREW, M4x16 - 2954-4016+H000 4 4
13 WASHER - 2600-4008+0767 2 4
14 CONNECTOR - 7012-7710+0 1 4
15 TRANSFORMER ASSY WITH
ROTARY SWITCH
299566 SVC-CURL11+TRAN 1
16 SCREW, M4x16 - 2954-4016+H000 2 4
17 WASHER - 2600-4008+H010 3 4
18 ROTARY SWITCH - 5200-4933+0 1 4
19 KNOB, TAP 295898-003 2447-3604+1 1
20 SCREW, M4x10 - 2904-4010+H000 4 4
21 SCREW, M3x10 - 2954-3012+H000 1 4
22 SCREW, M2.6x8 - 2954-2612+H000 1 4
23 SPRING - 2510-3941+0 1 4
24 WASHER - 2600-6212+1207 2 4
25 SCREW, M3x8 - 2954-4008+H000 1 4
26 BOSE LOGO ASSY, BLACK
BOSE LOGO ASSY, WHITE
303038-001
303038-002
2150-7191+0
2150-7192+0
1
- DS100SE BRACKET ASSY
(Includes 2 doors, strain relief, 4
screws, 4 washers & 1 spare
pivot screw)
BLACK
WHITE
315253-001
315253-002
BSACDS100+08CSX1
BSACDS100+08CSX2
1
- DS LDSPKR TRIM PLATE
(Includes any required mounting
hardware)
BLACK
WHITE
315266-001
315266-002
-
-
1
