ALTERNATE SETUP
Option 2
This figure shows two source connections using a coaxial cable (not provided) and
3.5 mm to RCA stereo cable (not provided).
Service
TV Input
R
L
CoaxialOptical
R
L
CoaxialOptical
AUX Optical Coaxial Power
Audio OUT
Source 2
Audio OUT
Source 1
Soundbar port panel
3.5 mm to RCA
stereo cable
(not provided)
Use two sources connected to the soundbar
Power o sources when not in use. In order for one source to deliver audio to the
soundbar, your other source must be o.
