Bose L1 Model II User Manual

Bose L1 Model II

32 pages

To Next Page

To Next Page

To Previous Page

To Previous Page

Page #29 background image

21

Venice_Care+Maint.fm 1/07

C

ARE AND MAINTENANCE

English Deutsch FrançaisDansk Español Italiano SvenskaNederlandsDansk Italiano SvenskaDeutsch NederlandsEnglish FrançaisEspañol

Limited Warranty and Registration

Your product is covered by a limited transferable warranty. Details of the warranty are

provided with your product. Register your products online at www.Bose.com/register or

call (800) 905-1044. Failure to do so will not affect your warranty rights.

Accessories

Visit www.Bose.com/musicians, or call (800) 905-0886 for accessory information.

Technical Information

Mechanical

Electrical

•AC power rating:

100-120V 50/60Hz 500W (USA/Canada); 220-240V 50/60Hz 500W (Europe)

• Peak inrush current:

32A @ 120V 60Hz (USA/Canada); 61A @ 230V 50Hz (Europe)

Audio Input/Output

• T1 ToneMatch

TM

port: DC output/data input Ethercon/RJ45 connector for a

T1 ToneMatch audio engine

• Analog Input: Line-level input channel for ¼" TRS phone plug

• Bass - Line Out: -4dBu (nominal), +9dBu (max.) (balanced TRS connection)

-10dBu (nominal), +3dBu (max.) (unbalanced TS connection)

• Bass Module Out: Neutrik NL4 output for one or two B1 bass modules

Dimensions Weight

L1

TM

model II power stand: 5''H x 10''W x 27''D

(12.8 cm x 26.2 cm x 69.2 cm)

23.7 lb

(10.7 kg)

L1 model II Cylindrical Radiator

®

loudspeaker top:

43½''H x 3½''W x 4''D

(11.1 cm x 9.0 cm x 10.5 cm)

16.3 lb

(7.4 kg)

L1 model II Cylindrical Radiator

®

loudspeaker bottom:

43½''H x 3½''W x 4''D

(11.1 cm x 9.0 cm x 10.5 cm)

17.4 lb

(7.9 kg)

B1 bass module: 15''H x 10¼''W x 17¾''D

(38.0 cm x 26.0 cm x 45.0 cm)

25.1 lb

(11.4 kg)

Impedance

L1

TM

model II Cylindrical

Radiator

®

loudspeaker: 4Ω

B1 bass module: 8Ω

Venice_Care+Maint.fm Page 21 Thursday, January 18, 2007 1:33 PM

Table of Contents

Other manuals for Bose L1 Model II

Technical Data Sheet8 pages

Questions and Answers:

B
Brooke ChandlerAug 23, 2025
What to do if my Bose Speaker System's power LED is green but there is no sound?
- S
  Stephanie OliverAug 23, 2025
  If the power LED on your Bose Speaker System is green but you're not hearing any sound, ensure that the volume control on your instrument is turned up. Also, check that the Trim level control is turned up on the power stand. Verify that your instrument is properly plugged into the Analog Input jack and try using a different cable to connect your instrument to the power stand. To rule out issues with your instrument, plug it into a different amplifier to confirm it's working correctly.
R
Rebecca JohnsonAug 25, 2025
How to fix a distorted sound from my Bose Speaker System?
- W
  wilsontimothyAug 25, 2025
  To fix a distorted sound from your Bose Speaker System, first check if the Signal/Clip LED is constantly red. If it is, lower the trim level. If the issue persists, try using a different audio source or instrument. You can also test your current source or instrument on another power stand to identify the problem.
S
simstomAug 25, 2025
Why is there no bass audio from my Bose Speaker System's B1 bass module?
- S
  stevenfernandezAug 26, 2025
  If your B1 bass module is plugged in but you're not hearing any bass audio, ensure you are using the included 4-wire B1 bass module cable. Verify that the cable is securely plugged into the Bass Module Out connector. Try using a different 4-wire cable and, if possible, test with a different B1 bass module to isolate the issue.
J
joshua04Aug 26, 2025
Why does my Bose Speaker System's B1 bass module sound out of balance?
- P
  patrickmccarthyAug 27, 2025
  If your B1 bass module sounds out of balance with the system, make sure you are using the B1 bass module 4-wire cable included with the B1 bass module package. Also, ensure that the B1 bass module grille is facing forward toward the musicians and audience.
M
Michael PottsAug 27, 2025
What to do if there are no mid/high sounds from Bose L1TM model II Cylindrical Radiator® loudspeaker?
- G
  Garrett MolinaAug 27, 2025
  If you are not hearing mid/high sounds from the L1 model II Cylindrical Radiator® loudspeaker, ensure the top and bottom sections are firmly seated in their connectors. Check for any bent or broken connections. You might also try cleaning the contacts on the loudspeaker top and bottom with an electronic contact spray cleaner.
R
Raymond CarterAug 28, 2025
Why does a third-party subwoofer sound poor with my Bose L1 Model II Speaker System?
- V
  Victoria WatsonAug 28, 2025
  If a third-party-powered subwoofer sounds poor when connected to the Bass - Line Out connector on the power stand: * Unplug any B1 bass modules connected to the power stand. * The signal from the Bass - Line Out may be too high for the powered subwoofer; try attenuating the signal using commercially available direct boxes or in-line pad devices. * Try different connections to the third-party-powered subwoofer, such as balanced or unbalanced cabling and/or a direct box. * Check that the gain and input controls on the third-party-powered subwoofer are set appropriately. * If using a powered subwoofer with an adjustable crossover, set the crossover to 180Hz.
J
Jeremy McdonaldAug 29, 2025
Why do my B1 bass modules sound poor when powered by a third-party amplifier with my Bose L1 Model II Speaker System?
- J
  Jordan ObrienAug 29, 2025
  If B1 bass modules powered by a third-party power amplifier and connected to the Bass - Line Out connector sound poor, ensure that at least two B1 bass modules are directly connected to the Bass Module Out connector on the power stand using a B1 bass module 4-wire cable. Check the gain settings on the third-party power amplifier, and ensure the volume level of the B1 bass modules powered by the power stand is similar to the bass modules powered by the external amplifier.
N
nashemmaAug 30, 2025
What to do if Bose Stereo System has power but no sound?
- C
  Christopher JordanAug 30, 2025
  If your Bose Stereo System has power LED on (green) but no sound, consider the following: * Ensure the volume control on your instrument is turned up. * Check that the Trim level control is turned up on the power stand. * Verify your instrument is plugged into the Analog Input jack. * Try a different cable to connect your instrument to the power stand. * Plug your instrument into a different amplifier to ensure the instrument is working.
J
Jerry RobinsonAug 31, 2025
How to troubleshoot Bose Stereo System with no power?
- M
  Mr. Benjamin YoungAug 31, 2025
  If the power LED is off on your Bose Stereo System even when plugged in and the power switch is on: * Ensure the AC outlet has power by testing it with a lamp or outlet tester. * Make sure the power cord is fully inserted into the AC outlet.
K
Kristen ElliottSep 1, 2025
What to do if Bose L1 Model II instrument or audio source sounds distorted?
- B
  bonnieyoungSep 1, 2025
  If your instrument or audio source sounds distorted, check the following: * Ensure the Signal/Clip LED isn't constantly red. If it is, lower the trim level. * Try using a different audio source or instrument. * Test your current source or instrument with another power stand.
