Bose L1 Pro16 Service Manual

13
Main Part List
L1 Pro16 I/O Panel Assy (see Figure 3)
Item
Number
Description Material
Number
Vendor Part
Number
Qty/Note
1 SCREW M3xL10_FLAT - T151301030610-02
2 SCREW, T3xL12(FOR JACK) - T153301210630
3 6.35MM STEREO JACK NJ6FD-VK - T710200019500
4
NON WOVEN SHEET FOR BUT-
TONS
- T182900003040
5 NON WOVEN SHEET_BLACK_AD-
HESIVE DS11 L46XW29.8XT0.3 K
- T182900003180
6 PE FOAM_BLACK_ADHSIVE
DS11 OD13XID8.5XT1.0
- T180500032780
7 PE FOAM_BLACK_ADHSIVE
DS11 OD16XID11.5XT1.0 K
- T180500032760
8 EVA_38 DEGREE_BLACK_ADHE-
SIVE DS11
- T180500030670
9 BUTTON MUTE - T100403300200
10 BUTTON PHANTOM - T100403400100
11 BUTTON SELECTION PC+ABS
94V0 BLACK K
- T100402900100
12 NON WOVEN SHEET FOR FIRE
BOX 1
- T182900003060
13 NON WOVEN SHEET FOR FIRE
BOX 2
- T182900003070
14 POLARITY LIGHT GUDIE - T100402300100
15 EVA_38 DEGREE_BLACK_ADHSIVE
DS11 L44XW24XT0.5 K
- T180500032750
16 SCREW, M3XL9 - T15130091C610
17 HOT MELT GLUE #1-286 - T980200000360-02
18 GREEN GLUE HAOZHENG: HD-
200G
- T980200000170
19 GASKET FOR PCB CONNECTOR 2 - T180500031150
20 OD9XT4MM - T180500032640
21 GASKET FOR FIRE BOX 2 843000-0120 T180500031100
22 ASSY, PCB, ANTENNA AND CABLE 796036-001S T690800019100
23 GASKET FOR FIRE BOX 3 843000-0110 T180500031120
24 THERMAL PAD 4 - T181700001690
25 SPRING WASER, M3 - T181200000270
26 HEATSINK EXTRUSION - T130217100100
27 SPACER 20.1 PA66-ROW 94V0
NATUR
- T100462000100
28 SPACER 24.4 PA66-ROW 94V0
NATUR
- T100461700100

Bose L1 Pro16 Specifications

General

Amplifier class	D
Frequency range	- Hz
RMS rated power	1250 W
Subwoofer peak power	1000 W
Sound pressure level (max)	124 dB
Amplifier	Built-in
Speaker type	-
Number of drivers	16
Built-in subwoofer	Yes
Subwoofer driver diameter (imperial)	18 \
Type	Freestanding Public Address (PA) system
Mounting type	Floor
Product color	Black
Volume control	Rotary
Number of mixer channels	3 channels
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	1
Power source type	AC

Weight and Dimensions

Depth	456 mm
Width	355 mm
Height	2012 mm
Weight	24800 g
