Bose L1 Pro16 Service Manual

17
Main Part List
L1 Pro16 Array Speaker (see Figure 4)
Item
Number
Description Material
Number
Vendor Part
Number
Qty/Note
1 SCREW T3xL12_FLAT
-
T153301230610-
02
2 END CAP ARRAY UPPER 826315-0110 T100424700100
3 GASKET FOR TOP ENDCAP - T180500031070
4 NON WOVEN ARRAY GRILLE - T182900003220
5 PUSH ON WASHER - T181200001410
6 GRILLE ARRY, SVCE (INCLUDES
BOSE LOGO)
863633-011S T130198500100
7 ARRAY LOGO NAMEPLATE - T100424600100
8 DOUBLE SIDE TAPE FR ARRAY LOGO - T180000008760
9 BAFFLE ARRAY COMMON - T100426200100
10 TW CONNECT SINGLE CABLE 120MM
X-P-1967 K
- T641700168700
11 ARRAY CABLE 6PIN
SMP396-2Y-01 K
- T641700170800
12 SCREW, T3xL10 - T15330101F611
13 NUT SPRING LOCK
M3X0.5PXH4MM
- T181000001460
14 NON WOVEN SHEET FOR GRILLE 1 - T182900003140
15 SCREW, M3xL12 - T151301210610
16 6PIN MOLEX 42475-6Y-VH-02 K - T641700171400
17 DRIVER, 2 IN 812886-0010 T911600010920 3
18 ARRAY LABEL - T911700056740
19 END CAP ARRAY LOWER 833733-0110 T100424400100
20 BAFFLE ARRAY LOWER - T100425800100
21 ENCLOUSRE ARRAY LOWER - T100425900100
22 FOAM STRIP FOR ARRAY 1 - T180200015730
23 FOAM FOR CALBE PLUG - T180500028000
24 GASKET FOR ARRAY ENCLOSURE - T180500031050
25 SCREW, T3xL15 - T15330151F610
26 BRACKET ARRAY COMMON - T13020810010A
27 ENCLOSURE CU ABS 94HB BLACK K - T100426300100
28 FOAM STRIP FOR ARRAY - T180200015810
29 ARRAY WADDING - T182700002500
30 HOT MELT GLUE XH150 - T980200000440
31 NON WOVEN SHEET - T182900003370

Bose L1 Pro16 Specifications

General

Amplifier class	D
Frequency range	- Hz
RMS rated power	1250 W
Subwoofer peak power	1000 W
Sound pressure level (max)	124 dB
Amplifier	Built-in
Speaker type	-
Number of drivers	16
Built-in subwoofer	Yes
Subwoofer driver diameter (imperial)	18 \
Type	Freestanding Public Address (PA) system
Mounting type	Floor
Product color	Black
Volume control	Rotary
Number of mixer channels	3 channels
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	1
Power source type	AC

Weight and Dimensions

Depth	456 mm
Width	355 mm
Height	2012 mm
Weight	24800 g
