Bose L1 Pro16 Service Manual

6
PRODUCT DESCRIPTION
L1 Pro16 Portable Line Array System is the most compact, most portable, play-anywhere system. The
system is ideal for Singer-Songwriter with 16 Twiddlers and one subwoofer.
Before connecting the system to a power source, assemble the system using the array extension and
mid-high array.
1. Insert the array extension into the subwoofer power stand.
2. Insert the mid-high array into the array extension.
The L1 Pro16 can be assembled without using the array extension; the mid-high array can be connected
directly to the subwoofer power stand. This conguration is most useful when on an elevated stage to be
sure the mid-high array is at ear level.
Array extension
Mid-high array
Subwoofer power stand

Bose L1 Pro16 Specifications

General

Amplifier class	D
Frequency range	- Hz
RMS rated power	1250 W
Subwoofer peak power	1000 W
Sound pressure level (max)	124 dB
Amplifier	Built-in
Speaker type	-
Number of drivers	16
Built-in subwoofer	Yes
Subwoofer driver diameter (imperial)	18 \
Type	Freestanding Public Address (PA) system
Mounting type	Floor
Product color	Black
Volume control	Rotary
Number of mixer channels	3 channels
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	1
Power source type	AC

Weight and Dimensions

Depth	456 mm
Width	355 mm
Height	2012 mm
Weight	24800 g
