Bose SoundTouch 120 User Manual

English - 17
Connecting the console to power
1. Plug the power cord into the Power connector on the console.
2. Plug the power cord into an AC (mains) outlet.
Installing the remote control’s batteries
1. Slide open the battery compartment cover on the back of the remote control.
2. Insert the two provided AA (IEC-LR6) 1.5V batteries. Match the + and –
symbols on the batteries with the + and – markings inside the compartment.
3. Slide the battery compartment cover back into place.
Starting up the System

Bose SoundTouch 120 Specifications

General

Cables included	HDMI, USB
Quick start guide	Yes
HDMI in	4
Number of HDMI outputs	1
AC input voltage	100-240 V
Bluetooth range	9 m
Product color	Black
Built-in HDD	No
Optical disc player type	Not included

Weight and Dimensions

Main unit weight	1490 g
Subwoofer weight	3400 g
Main unit dimensions (WxDxH)	313 x 208 x 64 mm
Subwoofer dimensions (WxDxH)	197 x 375 x 286 mm
