30 - English
Getting System Information
Using the System menu
Use the System menu to adjust audio levels, turn on/off features (such as
AUTO OFF), change the language, set the coaxial, analog and optical inputs for
a particular source, run the ADAPTiQ
®
audio calibration, pair your Acoustimass
®
module with the console or factory reset the system.
1. Press
on the remote.
2. Press
and to scroll through the System menu.
3. Press
and to adjust the settings.
4. Press
.
Display System state
1 AUDIO COMP
Off: (Default) No change to audio track.
Enhance dialogue: Increases the level of dialogue and sound
effects at low volume settings while
providing full audio impact at high volume settings.
Smart volume: Reduces the range of volume levels in a
movie soundtrack so the difference between extremely loud
outbursts and soft sounds is less noticeable.
Note: Enhance dialogue and smart volume features are not
available for SoundTouch
™
, Bluetooth
®
, or devices
connected to the connector.
2 AUDIO/VIDEO SYNC
Adjusts the audio delay to synchronize audio and video.
3 HDMI-CEC
Default On: (Default) Enables CEC (see page 22).
Alternate On: Prevents unintended source switching and may
fix CEC inconsistencies (see page 32).
Off: Disables CEC.
4 AUTO OFF
Enable: (Default) The system powers off after sixteen minutes
of inactivity (no sound coming from the system).
Disable: The system will not automatically power off.
5 SIDE AUX
Audio in: Sets the
connector for an auxiliary source.
Headphones: (Default) Sets the
connector as a head-
phone output.
Note: If set to Headphones and a cable is connected, the
soundbar is muted.
Disconnect your headphones when not in use.
6 BASS LEVEL
Adjusts bass level.
7 TREBLE LEVEL
Adjusts treble level.
To Next Page
