Bose SoundTouch SA-4 User Manual

Using the System
18 - English
Wall mounting the SoundTouch™ controller
WARNING: The wall mount bracket contains magnetic material. Please
contact your physician if you have any questions whether this might
affect the operation of your implantable medical device.
Follow these instructions to wall mount your SoundTouch
™
controller. Use the
bracket as a template to mark the holes.
Wallboard (anchors and screws supplied):
1. Use a ³/16 in. (5 mm) drill bit to drill two holes into ³/8 in. (9.5 mm)
or thicker wallboard.
2. Insert the provided anchors into the holes and tap lightly to secure.
3. Align the bracket (tab at top) to the anchors. Tighten the provided screws into
the holes.
4. Align the latch to the bracket's tab. Attach the controller.
Wood:
1. Purchase two #6x1 in. (25.4 mm) flat-head wood screws.
2. Use a
7
/64 in. (2.78 mm) drill bit to drill 2 holes into ³/4 in. (19 mm)
or thicker wood.
3. Align the bracket (tab at top) to the holes. Tighten the screws into the holes.
4. Align the latch to the bracket's tab. Attach the controller.
Tab
Bracket

Bose SoundTouch SA-4 Specifications

General

Amplifier class	-
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	- %
AC (power) in	Yes
USB 2.0 ports quantity	1
Speakers connectivity type	RJ-45
Purpose	Home
Product color	Black
Connectivity technology	Wired & Wireless

Weight and Dimensions

Depth	140 mm
Width	362 mm
Height	108 mm
Weight	5000 g
