9
T4S ToneMatch Audio Engine (see Figure 3)
MAIN PART LIST
Item
Number
Description Part Number Qty. Note
1 COVER ASSY, PROTECTIVE, T4, SVCE (INCLUDES ITEMS 2
AND 3)
797487-011S 1
2 MAGNET ASSY - 8
3 COVER, MAGNET, RUBBER, BLK, SVCE 797586-011S 4
4 KNOB, LCD, SVCE 792627-011S 3
5 KNOB, CHANNEL VOLUME, SVCE 792629-011S 5
6 KNOB, MASTER VOLUME, SVCE 792628-011S 2
7 T4S PC PANEL TRANSPARENCY, ADHESIVE - 1
8 SCREW, T2.0XL8, P0.6, BZN+CED+HT - 2
9 T4S AL PANEL, AL1050, BLK ANODIZE - 1
10 PANEL ASSY, UI, T4, SVCE (INCLUDES ITEMS 7 AND 9) 797306-011S
11 EVA E-4308 ADHESIVE, PET, BLACK - 1
12 ASSY, LCD DISPLAY, 4CH/8CH, SVCE 797353-001S 1
13 PUSH BUTTON, SILICONE, SVCE 792631-011S 1
14 CONDUCTIVE FOAM, ADHESIVE, BLK - 1
15 PCB ASSY MAIN, 4CH, SVCE 797348-001S 1 1
16 T4S PET SHT, 40X14X2.0, ADHESIVE - 1
17 COVER, BOTTOM, T4, SVCE 792621-011S 1
18 PRODUCT LABEL, T4S - 1
19 KNOB, TRIM, SVCE 792625-011S 4
20 KNOB, PHANTOM, SVCE 792626-011S 1
21 NUT, 1/4 JACK, SVCE 797355-011S 6
22 SCREW, T.30XL12, 1.058P, ZN-NI - 14
23 STAND OFF, PCB, SVCE 797414-001S 4
24 PCB ASSY I/O, 4CH, SVCE 797351-001S 1 1
25 HARNESS, WIRE, IDC, SVCE 797346-001S 2
26 LIGHT GUIDE, PC+ABS, 94V0, BLACK - 1
27 POWER SWITCH, ASSY, SVCE 797347-001S 1
28 LED HOUSING, NYLON 66, BLACK (INCLUDED WITH ITEM
15)
- 1
29 SCREW, T3.0XL18, 1.058P, BZN+CED+HT - 5
30 PLUG, SCREW, RUBBER, BLK, SVCE 797584-011S 1
31 FOOT, RUBBER, BLK, SVCE 797587-011S 4
- PUSH TAB, XLR, SVCE 797358-011S 2
To Next Page
