KNOWING YOUR SEWING MACHINE ————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
—
————————————————————————————————————————————————
—————
21
0
Pass the end of the thread through the
presser foot, and then pull out about 5 cm
(2 inches) of thread toward the rear of the
machine.
1 5 cm (2 inches)
Note
● If you incorrectly feed the thread you may
cause sewing problems.
Drawing up the lower
thread
1
While lightly holding the end of the upper
thread, slowly turn the handwheel toward
you (counterclockwise) by hand to lower
and then raise the needle.
2
Pull on the upper thread to draw up the
lower thread.
1 Upper thread
2 Lower thread
3
Pull out about 10 cm (4 inch) of both
threads and put them toward the back of
the machine under the presser foot.
1 Upper thread
2 Lower thread
■ For models equipped with a quick-set
bobbin
You can begin sewing immediately without drawing
up the bobbin thread.
When sewing gathers or darts, you can draw up the
lower thread by hand so that some thread will be
left over. Before you draw up the lower thread, put
the bobbin back in.
1
Remove the bobbin cover, and then
reinstall the bobbin.
2
Pass the thread along the slit in the
direction of the arrow, and leave it there
without cutting it.
• The bobbin cover should still be removed.
3
Draw up the lower thread as described in
the previous steps
1 to 3.
4
Replace the bobbin cover.
1
1
1
2
2
1
2

Brother BM3700 Specifications

General

Type	Automatic sewing machine
Free arm	Yes
Product color	White
Buttonhole type	-
Number of programs	74
Sewing machine functions	Sewing
Number of stitch patterns	37
Power supply type	Electric

Weight and Dimensions

Depth	159 mm
Width	389 mm
Height	300 mm
