Brother BX3000 User Manual

KNOWING YOUR SEWING MACHINE ————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
—
————————————————————————————————————————————————
—————
13
THREADING THE MACHINE
Winding the bobbin
CAUTION
a
Pull up the spool pin and put a spool of
thread on this pin.
b
While holding the thread from the spool
with your right hand, pass the thread
toward you, in the groove on the thread
guide. Then, pass the thread around the
pre-tension disk and pull the thread in
completely.
CAUTION
● We designed the bobbin that comes with this machine. If you use bobbins from other models,
the machine will not work properly. Only use the bobbin that comes with this machine or
bobbins of the same type (part code: SA156, SFB: XA5539-151). Using other bobbins may
cause damage to the machine. SA156 is Class 15 type bobbin.
Actual size
11.5 mm
(7/16 inch)
This model Other models
1 Pre-tension disk 2 Bobbin winder shaft 3 Bobbin
3
2
1
1 Pull the thread
in completely.
● If the spool of thread is in the wrong
place, or is set incorrectly, the thread
may tangle on the spool pin.

Brother BX3000 Specifications

General

Sewing machine accessories included	Zigzag foot
Power supply type	-
Display	No
Free arm	Yes
Sewing speed	750
Stitch width	5 mm
Product color	Violet, White
Stitch length	4 mm
Number of programs	20
Sewing machine functions	Sewing
Number of stitch patterns	2
Number of needle positions	3

Weight and Dimensions

Depth	392 mm
Width	148 mm
Height	308 mm
Weight	4700 g
