Brother DCP-8250DN Service Manual

5-27
Confidential
1.3.16 Fine-tune scanning position (function code: 54)
<Function>
This function is used to adjust the scanning start/end positions for the ADF and the document
scanner unit.
<Operation Procedure>
(1) Press the [5] and [4] buttons in this order in the initial state of maintenance mode. "SCAN
START ADJ." is displayed on the LCD.
(2) After two seconds, " : ADF : FB" is displayed on the LCD. Select the item you want
to adjust the start position. Press [ ] to select the ADF and [ ] to select the document
scanner unit.
(3) Duplex scanning models
: After two seconds, " : FRONT : BACK" is displayed on the
LCD. Select the item you want to adjust the start position. Press [ ] to select the first
side and [ ] to select the second side.
Single-side scanning models
: Proceed to step (4).
(4) The current scanning position compensation level is displayed on the LCD.
(Compensation levels can be adjusted in 11 steps from 5 to -5.)
(5) Press the [ ] button to adjust the compensation level in the positive direction or press
the [ ] button to adjust it in the negative direction.
(6) Press the [OK] button. "Accepted" is displayed on the LCD, and the machine returns to
the initial state of maintenance mode.
1.3.17 Acquire white level data and set CIS scan area (function code: 55)
<Function>
This function is used to obtain the white level of the CIS unit, and store this data and the scan
area in the EEPROM of the main PCB.
<Operation Procedure>
(1) Press the [5] button twice in the initial state of maintenance mode. "Press START" is
displayed on the LCD.
(2) Press the [Start] button. "SCANNER AREA SET" is displayed on the LCD, and the white
level data is obtained.
(3) After several seconds, the compensation value for the white level data/scanning width is
stored in the EEPROM, and the machine returns to the initial state of maintenance
mode.
If any error is detected during this operation, "SCANNER ERROR" is displayed on the
LCD for single-side scanning models, and "SCANNER ERR ADF" or "SCANNER ERR
FB" for duplex scanning models.
When the [Stop/Exit] button is pressed, the machine returns to the initial state of
maintenance mode.
Note:
• In the event that the correct white level cannot be obtained when this function is
executed after the machine is released from Deep Sleep mode, install the latest
firmware. If the firmware cannot be installed, open the front cover and then close it
again, and wait until the main motor completely stops. Then retry installing the firmware.

Brother DCP-8250DN Specifications

General

Secure printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
PictBridge	No
Scan speed	2.68 sec/page
Dimensions (WxDxH)	491 x 415 x 477 mm
All-in-one functions	Copy, Print, Scan
Networking standards	IEEE 802.11b, IEEE 802.11g
Color all-in-one functions	Scan
Printing colors	Black
Maximum duty cycle	- pages per month
Recommended duty cycle	1000 - 5000 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 6
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4, 9, 16, 25
Time to first copy (black, normal)	10.5 s
Copy speed (black, normal quality, A4)	40 cpm
Scan to	E-mail, E-mail Server, File, FTP, Image, OCR, USB
Scan drivers	ISIS, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan area	Legal (216 x 356) mm
Output color depth	24 bit
Image formats supported	BMP, JPG
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	PDF
Paper input type	Paper tray
Total input capacity	500 sheets
Total output capacity	150 sheets
Maximum input capacity	1050 sheets
Maximum number of input trays	2
Auto document feeder (ADF) input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper, Thin paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Business cards, Envelopes, Heavyweight paper, Labels, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Display	TFT
Control type	Touch
Display diagonal	4.9 \
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, EAP, EAP-TLS, EAP-TTLS, MD5, PEAP, SSL/TLS, TKIP, WPA-AES, WPA-PSK, WPA2-PSK
Processor family	Star Sapphire
Maximum internal memory	384 MB
Sound power level (standby)	37 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.45 W
Power consumption (standby)	9.8 W
Power consumption (PowerSave)	350 W
Power consumption (average operating)	694 W
Package weight	21.900 g
Sustainability certificates	ENERGY STAR
