Brother DSMOBILE 600 User Manual

Windows
®
Operation
14
1
CLEANING THE SCANNER
Note
The cleaning procedure can be initiated in the DSMobileScan II software program. It is recommended to
place a few drops of alcohol (70% isopropyl alcohol) in the middle of the cleaning sheet.
Note
Use the cleaning sheet included in the original packaging. If the original cleaning sheet is not available you
may order a new cleaning sheet on the Brother Mall, brothermall.com. The cleaning sheet is available in
a kit containing one cleaning sheet and two calibration sheets, the kit part number is M1004.
a First plug the scanner into the USB port of your computer. Let a few seconds pass while your PC has
recognized the scanner then press the black button on the top of the scanner. From the box select a
TWAIN or WIA compliant application, such as DSmobileScan II. The following box should appear.

Brother DSMOBILE 600 Specifications

General

Film scanning	No
Color scanning	Yes
Grayscale levels	8
Input color depth	48 bit
Maximum scan size	216 x 356 mm
Optical scanning resolution	6400 x 9600 DPI
Scanner type	Sheet-fed scanner
Safety	FCC Class B, CE
Dimensions (WxDxH)	51 x 279 x 38 mm
Sensor type	CMOS CIS
USB version	2.0
Standard interfaces	USB 2.0
Minimum RAM	128 MB
Minimum processor	Pentium 2
Minimum storage drive space	200 MB
Minimum system requirements	VGA USB 2.0 Cd-ROM
Compatible operating systems	Windows Vista, XP, 2000, ME, 98 SE
Power consumption (off)	0.02 W
Power consumption (standby)	0.2 W
Power consumption (typical)	2 W
Certification	RoHS, WEEE

Weight and Dimensions

Weight	345 g
