Brother DSMOBILE 600 User Manual

Using Scanning Software
32
3
PageManager
®
9 (For Windows
®
)
This program makes it easy to scan, share, and organize your photos and documents. It helps you not only
convert piles of paper into organized digitized files, but also lets you view, edit, send, and back-up files in
many formats.
To install PageManager
®
, see PageManager
®
9 Installation (For Windows
®
) uu page 5. Refer to the
“help” file included with this program for further use instructions.
Initial Setup with PageManager
®
9
Note
Calibration is a critical step in setting up your scanner. This process will balance the image quality between
your computer and the scanner unit. If at any time you switch the scanner to another computer then you
will need to reinstall the scanner driver and recalibrate the scanner.
Selecting Scanning Source
a When using Presto! PageManager
®
9 for the first time you will need to define the Scanning Source this
application will be using. This also applies when switching to another scanner.
b Run the PageManager
®
9 application and select file in the toolbar menu.
c Under file pull-down menu choose the Select Source option, then your model.

Brother DSMOBILE 600 Specifications

General

Film scanning	No
Color scanning	Yes
Grayscale levels	8
Input color depth	48 bit
Maximum scan size	216 x 356 mm
Optical scanning resolution	6400 x 9600 DPI
Scanner type	Sheet-fed scanner
Safety	FCC Class B, CE
Dimensions (WxDxH)	51 x 279 x 38 mm
Sensor type	CMOS CIS
USB version	2.0
Standard interfaces	USB 2.0
Minimum RAM	128 MB
Minimum processor	Pentium 2
Minimum storage drive space	200 MB
Minimum system requirements	VGA USB 2.0 Cd-ROM
Compatible operating systems	Windows Vista, XP, 2000, ME, 98 SE
Power consumption (off)	0.02 W
Power consumption (standby)	0.2 W
Power consumption (typical)	2 W
Certification	RoHS, WEEE

Weight and Dimensions

Weight	345 g
