HE-800A
iv
3. Warning labels
The following warning labels appear on the sewing machine.
Please follow the instructions on the labels at all times when using the machine. If the labels have been removed or are
difficult to read, please contact your nearest Brother dealer.
12
3
Be sure to connect the ground. If the ground
connection is not secure, you run a high risk of
receiving a serious electric shock, and problems
with correct operation may also occur.
Safety devices
Eye guard
Finger guard
Thread take-up cover
Belt cover
Belt cover plate, etc.
4
Do not touch any of the cutter or press any
objects against the machine while sewing, as
this may result in personal injury or damage to
the machine.
6
High temperature
warning display
5
Do not touch any of the fan or press any objects
against the machine, as this may result in
personal injury or damage to the machine.
7
Direction of operation
3852Q
Belt cover plate
Belt cover
Thread take-up cover
Eye guard
Finger guard
To Next Page
