Brother MFC-J1010DW User Manual

Home > Security > Use IEEE 802.1x Authentication for a Wired or a Wireless Network > Configure IEEE
802.1x Authentication for a Wired or a Wireless Network Using Web Based Management (Web Browser)
Configure IEEE 802.1x Authentication for a Wired or a Wireless Network
Using Web Based Management (Web Browser)
• If you configure your machine using EAP-TLS authentication, you must install the client certificate issued
by a CA before you start configuration. Contact your network administrator about the client certificate. If
you have installed more than one certificate, we recommend writing down the certificate name you want to
use.
• Before you verify the server certificate, you must import the CA certificate issued by the CA that signed the
server certificate. Contact your network administrator or your Internet Service Provider (ISP) to confirm
whether a CA certificate import is necessary.
You can also configure IEEE 802.1x authentication using Wireless setup wizard from the control panel
(Wireless network).
1. Start your web browser.
2. Type "https://machine's IP address" in your browser's address bar (where "machine's IP address" is the
machine's IP address).
For example:
https://192.168.1.2
• If you are using a Domain Name System or enable a NetBIOS name, you can type another name, such
as "SharedPrinter" instead of the IP address.
- For example:
https://SharedPrinter
If you enable a NetBIOS name, you can also use the node name.
- For example:
https://brnxxxxxxxxxxxx
The NetBIOS name can be found in the Network Configuration Report.
3. If required, type the password in the Login field, and then click Login.
The default password to manage this machine’s settings is located on the back of the machine and marked
"Pwd".
4. Go to the navigation menu, and then click Network.
Start from
, if the navigation menu is not shown on the left side of the screen.
5. Do one of the following:
• For the wired network
Click Wired > Wired 802.1x Authentication.
• For the wireless network
Click Wireless > Wireless (Enterprise).
6. Configure the IEEE 802.1x authentication settings.
316

Brother MFC-J1010DW Specifications

General

Duplex printing	Yes
Print technology	Inkjet
Maximum resolution	1200 x 6000 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	17 ppm
Envelopes sizes	C5, Com-10, DL, Monarch
Paper tray media types	Glossy paper, Plain paper, Recycled paper
Paper tray media weight	64 - 220 g/m²
Non-ISO print media sizes	Index card
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO C-series sizes (C0...C9)	C5
Photo paper sizes (imperial)	3.5x5, 4x6, 5x7, 5x8 \
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	64 - 300 g/m²
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Ethernet LAN	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	64-bit WEP, 128-bit WEP, AES, EAP-FAST, EAP-TLS, EAP-TTLS, HTTPS, IPPS, PEAP, SSID, SSL/TLS, TKIP, WPA-PSK, WPA2-PSK
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print
Internal memory	128 MB
Duplex copying	-
Maximum copy resolution	1200 x 1200 DPI
Copy speed (black, normal quality, A4)	11.5 cpm
Copy speed (color, normal quality, A4)	4 cpm
Display	LCD
Control type	Buttons, Touch
Product color	Grey, White
Display diagonal	2.67 \
Market positioning	Home & office
Scan to	E-mail, File, Image, OCR
Scanner type	Flatbed & ADF scanner
Optical scanning resolution	1200 x 2400 DPI
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Windows operating systems supported	Windows 10, Windows 11, Windows 8
Fax transmission speed	14400 sec/page
Sustainability certificates	Blue Angel
Package depth	249 mm
Package width	477 mm
Package height	457 mm
Package weight	9700 g
Cables included	AC
Bundled software	NewSoft Presto! PageManager 9 Brother iPrint & Scan, ScanSoft Paperport 14 SE.
Printing colors	Black, Cyan, Magenta, Yellow
Duplex functions	Print
Maximum duty cycle	- pages per month
Number of print cartridges	4
Total input capacity	170 sheets
Total output capacity	50 sheets
Paper tray 1 input capacity	150 sheets
Total number of input trays	2
Auto document feeder (ADF) input capacity	20 sheets
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	343 mm
Width	400 mm
Height	172 mm
Weight	8100 g
