BUSCH R5 RC 0021 C User Manual

Technical Data | 13
Instruction Manual R5 RB_RC 0021 C_EN_en 25 | 32
13 Technical Data
RB 0021 C RC 0021 C
Nominal pumping speed
(50Hz / 60Hz)
m³/h 20 /24 20 /24
ACFM 11.7 / 14.1 11.7 / 14.1
Ultimate pressure
(without gas ballast valve)
hPa (mbar) abs. 2.0 20
torr 1.5 15
Ultimate pressure
(with gas ballast valve)
hPa (mbar) abs. 2.0 20
torr 1.5 15
Nominal motor speed
(50Hz / 60Hz)
min
-1
3000 / 3600
rpm
Nominal motor rating
(50Hz / 60Hz)
kW 0.75 / 0.9 0.75 / 0.9
HP - / 1 - / 1
Power consumption at 100 mbar
(50Hz / 60Hz)
kW 0.78 / 1.03 0.78 / 1.03
HP - / 1.5 - / 1.5
Power consumption at ultimate
pressure (50Hz / 60Hz)
kW 0.56 / 0.79 0.7 / 0.9
HP - / 1 - / 1
Noise level (ENISO2151)
(50Hz / 60Hz)
dB(A) 66 / 72
Ambient temperature range °C 5 ... 40
°F 41 … 104
Ambient pressure Atmospheric pressure
Oil capacity L 0.45
qts 0.47
Weight approx. Kg ~20
lbs ~44
