5 Installation
5.1 Installation Conditions
NOTICE
Use of the machine outside of the permitted installation conditions.
Risk of premature failure!
Loss of efficiency!
● Take care that the installation conditions are fully complied with.
● Make sure that the environment of the machine is not potentially explosive.
● Make sure that the ambient conditions comply with the Technical Data [➔25].
● Make sure that the environmental conditions comply with the protection class of the motor and
the electrical elements.
● Make sure that the installation space or location is vented such that sufficient cooling of the ma-
chine is provided.
● Make sure that cooling air inlets and outlets are not covered or obstructed and that the cooling
air flow is not affected adversely in any other way.
● Make sure that the oil sight glass (OSG) remains easily visible.
● Make sure that enough space remains for maintenance work.
● Make sure that the machine is placed or mounted horizontally, a maximum of 1° in any direction
is acceptable.
● Check the oil level, see Oil Level Inspection [➔17].
● Make sure that all provided covers, guards, hoods, etc. are mounted.
If the machine is installed at an altitude greater than 1000 meters above sea level:
● Contact your Busch representative, the motor should be derated or the ambient temperature
limited.
