1.5 09/2010 © CAME cancelli automatici s.p.a. - The data and information reported in this installation manual are susceptible to change at any time and without obligation on CAME cancelli automatici s.p.a. to notify users.
ENGLISH
4.1 Turnstile
4 Description
2.1 Intended use
1 Legend of symbols
This symbol shows parts to be read carefully.
This symbol shows parts related to safety.
This symbol shows what to tell users.
The TWISTER electromechanical turnstile is designed to select transit flows in high-volume passage areas, and in highly fre-
quented contexts like stadiums, airports, stations, public buildings and in any other places where high-volume flows need to be
regulated and/or selected
Any installation or use other than that shown in this manual is prohibited.
3 Reference Legislation
IMPORTANT SAFETY INSTRUCTIONS FOR INSTALLATION
WARNING: WRONG INSTALLATION MAY CAUSE SERIOUS INJURY, FOLLOW ALL INSTALLATION INSTRUCTIONS
THIS MANUAL IS EXCLUSIVELY MEANT FOR PROFESSIONAL INSTALLERS OR OTHER COMPETENT PERSONS
This product is designed and built by CAME Cancelli Automatici S.p.A. in compliance with the current safety legislation.
It allows passage in the desired direction of one person a time. By activating a command device, the mechanism releases the tripod
which rotates freely allowing people to pass through; the arms automatically return into place and the mechanism locks immediately
after a single passage, waiting for a new command.
The range includes:
001PST001 - Bi-directional electromechanical tripod turnstile AISI 304 steel with scotch-brite fi nishing, complete with ocntrol board,
transponder sensors and high-luminosity LED bi-directional traffi c light with display. Tripod automatic release in case of blackout.
Power: 230 V AC 50 / 60 Hz
Power Draw: 260 mA max
Insulation class: II
Protection rating: IP44
Weight: 60 Kg
The product being described herein complies with the following legislation: see compliance statement.
4.2 Technical Data
2 Intended use and limits
