External Connections
This chapter explains how to connect your camcorder to an external
device such as a TV, VCR, or computer.
Connection Diagrams
Terminals on the Camcorder
AV OUT Terminal
Access: Open the LCD panel.
Sound from the built-in speaker will be muted while the
STV-250N Stereo Video Cable is connected to the
camcorder.
USB Terminal
Access: Open the LCD panel.
Connection
Type: Analog Output only
Connect to a TV or VCR with audio/video input terminals. If the TV cannot automatically
detect and change the aspect ratio ( 80), change [TV TYPE] according to the TV set
(widescreen or 4:3).
Connection
Type: Digital data connection
Connect to a computer to transfer and back up your recordings, to the optional
DW-100 DVD Burner to create DVD discs from them, or to a printer to print out photos.
VIDEO
AUDIO
R
L
STV-250N Stereo Video Cable
(supplied)
Yellow
White
Red
USB Cable (supplied)
