Parts List
Key Part Number Rank Q’ty Description Remark
Common
parts
QY6-0054-000 K 1 PRINT HEAD B
1 QC1-4988-000 J 1 PAPER SUPPORT
2 QM2-1428-000 J 1
UPPER COVER UNIT, WITH
BUTTON
3 QC1-4991-000 J 1 COVER, I/F
QC1-5005-000 J 1 EMBLEM (E) B
4
QC1-5009-000 J 1 EMBLEM (J) B
5 QC1-5019-000 J 1 LABEL, PIXMA (E)
6 QM2-1441-000 I 1 FRONT COVER
7 QM2-1477-000 I 1 LOGIC BOARD ASS’Y
QK1-0756-000 I 1 AC ADAPTER: 100/120V 50/60HZ LV
8
QK1-0757-000 N 1 AC ADAPTER: 220/240V 50/60HZ HV (EUR/ASIA/AU/KR/HK/GB/EUM)
9 QC1-5104-000 I 1 FILM, TIMING SLIT STRIP
10 QC1-4998-000 I 1 SPRING, TIMING SLIT STRIP FILM
11 QC1-1690-000 I 1 LOCK LEVER.BLADE C
12 QM2-1445-000 I 1 CAP UNIT C
13 QM2-1443-000 I 1 BLADE UNIT C
14 QC1-4975-000 I 1 ABSORBER 1, INK MAIN WASTE INK ABSORBER 1
15 QC1-4976-000 I 1 ABSORBER 2, INK MAIN WASTE INK ABSORBER 2
16 QM2-1847-000 I 1 ABSORBER, PLATEN PLATEN WASTE INK ABSORBER
S1 XA9-1493-000 G SCREW, TP M3X8 FOR AC ADAPTER
FOR UPPER CASE UNIT
C
S2 XB6-7300-605 G SCREW, TP M3X6 MM FOR LOGIC BOARD ASS’Y
FOR LF MOTOR
C
S3 XB1-2300-405 G SCREW, M3X4 FOR TIMING SLIT STRIP FILM SPRING C
Power cables:
QH2-2720-000 S 1 CORD, POWER 120V (LAM-LV) A
QH2-2724-000 S 1 CORD, POWER 100V-120V (JP) B
QH2-2725-000 S 1 CORD, POWER 100V-120V A
QH2-2726-000 S 1 CORD, POWER 220V-240V A
QH2-2727-000 S 1 CORD, POWER 220V-240V (AU) A
WT3-5156-000 S 1 CORD, POWER 220V-240V (GB, HK) A
WT3-5160-000 S 1 CORD, POWER 220V-240V (KR) A
WT3-5182-000 S 1 CORD, POWER 220V-240V (CHN) A
A: In common with the iP2000 and iP1000
B: In common with the iP2000
C: In common with the iP1000
