1.1.2 Pickup/ Delivery /Original Handling Accessories System Configuration (iR2016/iR2016J)
0011-0892
iR2016J / iR2016
The configuration is as shown in the following figure:
F-1-2
*1: This accessory comes standard with the models for Asia excluding Taiwan and the models for some Latin American countries.
*2: A Cassette feeding module-J1 can be placed on the Cassette feeding module-K1 to use these cassette units as a 3-stage cassette unit.
*3: This accessory is required when the Finisher-U1, Inner 2-way tray-E1, Cassette feeding module-K1 or Duplex unit-A1 is installed. This accessory comes
standard with the iR2016 for North America, Latin America and Asia.
[1] DADF-P1
[2] Platen Cover Type J *1
[3] Finisher-U1
[4] Additional Finisher Tray-C1
[5] Inner 2-way Tray-E1
[6] Cassette Feeding Module-J1 *2
[7] Cassette Feeding Module-K1 *2
[8] Duplex Unit-A1
[9] Power Supply Kit-Q1 *3
[10] Document Tray-J1
[11] Card Reader-E1
[3]
[2]
[10]
[4]
[5]
[7]
[7]
[6]
[8]
[9]
[11]
[6]
[1]
