16
2. Installation and Connections
Using Two Analog COMPUTER Inputs Simultaneously (LV-7265)
If you need to use two analog inputs simultaneously, connect a VGA cable as shown below.
AUDIO IN
AUDIO OUT
S
-
VIDEO
IN
VIDEO
IN
L
AUDIO IN
R
SERVICE PORT
ANALOG IN-1
DIGITAL IN /
ANALOG IN-2
DIGITAL IN /
ANALOG IN-2
ANALOG IN-1
NOTE: When the DVI to VGA adapter is not to be used for an extended period of time, remove it from the projector. Failure to do
so may cause damage to the connector of the projector.
IBM PC or Compatibles (Desktop type)
or Macintosh (Desktop type)
IBM VGA or Compatibles (Notebook
type) or Macintosh (Notebook type)
VGA cable
(supplied)
DVI to VGA adapter
(supplied)
VGA cable
(not supplied)
To Next Page
