Basic Printing
21
Performing Infrared Communication
When performing infrared communication, also refer to your computer, mobile phone
or PDA manual.
1 Set up the Printer.
(1) Ensure that the Universal AC Adapter is connected securely.
When using the optional battery, ensure that it has been charged.
(2) Open the Paper Support and turn on the printer.
(3) Load the paper on the Paper Support.
2 Start Infrared Communication.
(1) Align the Infrared Port of the computer to that of the printer at a distance of less
than 31.5 inch (80 cm). When printing from a mobile phone or PDA, place it at a
distance of less than 7.87 inch (20 cm).
The effective angle of the Infrared Port of the printer is about 10° from the
central axis in both vertical and horizontal directions.
The allowable distance of communication with the printer depends on the
computer, mobile phone or PDA you use. For this distance, refer to your
computer, mobile phone or PDA manual.
Less than 31.5 inch (80
cm)(Do not block with any
obstacle.)
Effective angle
(in both vertical and
horizontal direction): About
10°
Infrared Port of printer
Infrared Port of computer
When printing with the computer
When printing with the computerWhen printing with the computer
When printing with the computer
iP90_QSG_US.book Page 21 Thursday, December 7, 2006 11:03 AM
To Next Page
