Canon XF100 User Manual

143
Menu Options
[ND Filter]: Allows the camcorder to control the ND filter automatically. When the ND filter is activated, the icon of
one of three available settings - 1/2 (NDu), 1/4 (NDw) and 1/8 (NDx) -will appear on the screen.
[Soft Zoom Control]: When this setting is activated, the zoom will start and/or stop gradually.
[Both]: Affects both when you start and when you stop zooming.
[Stop]: Affects only when you stop zooming.
[Start]: Affects only when you start zooming.
[Tele-converter]: Determines the operation of the digital tele-converter. When activated, the focal length of the
camcorder increases by a factor of approximately 1.5, 3 or 6, depending on the setting.
• The image is digitally processed, so the image resolution may deteriorate.
[Slow Shutter]: Activates the slow shutter for Infrared mode.
Custom picture
[X Edit File] settings
[Tele-converter] [6.0x], [3.0x], [1.5x], [Off] –
[Flicker Reduction] [Automatic], [Off] 56
[Conversion Lens] [TL-H58], [WD-H58W], [Off] –
[Color Bars] [Enable] [On], [Off]
80
[Type] [Type 1], [Type 2]
[Infrared] [Monochrome] [White], [Green] 90
[Light] [Toggle], [Always On], [Always Off] 90
[Slow Shutter] [On], [Off] –
[Custom Picture] [X Select File] Custom picture files in the camcorder and SD card. 96
[X Edit File] Refer to the following table for setting options and default values. 97
[X Transfer File] For custom picture files in the camcorder:
[Copy To b], [Load From b]
For custom picture files on the SD card:
[Copy To Cam.], [Load From Cam.]
98
Menu item Submenu Setting options 0
[Rename] 97
[Protect] [Unprotect], [Protect] 97
[Reset] [Cancel], [OK] 97
[Gamma] [Normal 1], [Normal 2], [Normal 3], [Normal 4],
[Cine 1], [Cine 2]
99
[Black] [Master Pedestal] -50 to 50 (0)
99
[Master Black] [Red] -50 to 50 (0)
[Green] -50 to 50 (0)
[Blue] -50 to 50 (0)
[Black Gamma] [Level] -50 to 50 (0)
100[Range] -5 to 50 (0)
[Point] -1 to 50 (0)
[Low Key Satur.] [Enable] [Off], [On]
100
[Level] -50 to 50 (0)
Menu item Submenu Setting options 0
COPY

Canon XF100 Specifications

General

Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/3 \
Effective megapixels (movie)	2.07 MP
Filter size	58 mm
Digital zoom	6 x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	4.25 - 42.5 mm
Interchangeable lens	-
Focal length (35mm film equivalent)	30.4 - 304 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	CF, SD, SDHC, SDXC
Maximum memory card size	32 GB
Internal storage capacity	- GB
Focus adjustment	Auto/Manual
Scene modes	Backlight, Spotlight
Light exposure modes	Auto
Camera shutter speed	1/3 - 1/2000 s
Display diagonal	3.5 \
Viewfinder resolution	260000 pixels
Viewfinder screen size	0.24 \
Photo effects	Black&White
Camcorder type	Handheld camcorder
Image processor	DIGIC DV III
Minimum illumination	0.7 lx
Product color	Black
Video resolutions	1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Maximum frame rate	50 fps
Video formats supported	MPEG2, MXF
Maximum video resolution	1920 x 1080 pixels
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	1
Battery capacity	- mAh
Battery life (max)	- h
Operating temperature (T-T)	-5 - 45 °C

Weight and Dimensions

Depth	268 mm
Width	139 mm
Height	191 mm
Weight	1120 g
