Preparing Recording Media
34
Preparing Recording Media
The camcorder records clips to CompactFlash (CF) cards and photos* to SD and SDHC memory
cards. The camcorder is equipped with two CF card slots. Initialize recording media (0 36) when you use them
with this camcorder for the first time.
* The camcorder can record custom picture settings (0 98) and camera settings (0 106) on to an SD card. To record a user
memo (0 79) with a clip, use the supplied Canon XF Utility software to a create user memo file and save it to the SD card. The
camcorder can read the file and embed it in the clip.
Compatible CF cards
You can use UDMA-compatible* Type I CF cards with a capacity of at least 512 MB with the camcorder. For
more details on cards that can be used, visit your local Canon Web site.
* The Ultra Direct Memory Access (UDMA) specification allows data to be transferred between the CF card and device at high
transfer speeds (measured in MBps). Depending on the CF card, you may not be able to record even when using a UDMA-
comptaible CF card.
NOTES
• Proper operation cannot be guaranteed for all CF cards.
Inserting a CF Card
You can insert a CF card into CF card slot A or slot B. If you have two CF
cards, you can use both slots.
1 Slide the CF card slot cover switch in the direction of the E/A
mark (햲).
• The CF card slot cover will open to the left (slot A) or to the right
(slot B).
2 Insert the CF card straight, with the label facing away from the
lens, all the way into the slot until it clicks (햳).
3 Close the CF card slot cover.
• Do not force the cover closed if the CF card is not correctly inserted.
COPY

Canon XF100 Specifications

General

Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/3 \
Effective megapixels (movie)	2.07 MP
Filter size	58 mm
Digital zoom	6 x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	4.25 - 42.5 mm
Interchangeable lens	-
Focal length (35mm film equivalent)	30.4 - 304 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	CF, SD, SDHC, SDXC
Maximum memory card size	32 GB
Internal storage capacity	- GB
Focus adjustment	Auto/Manual
Scene modes	Backlight, Spotlight
Light exposure modes	Auto
Camera shutter speed	1/3 - 1/2000 s
Display diagonal	3.5 \
Viewfinder resolution	260000 pixels
Viewfinder screen size	0.24 \
Photo effects	Black&White
Camcorder type	Handheld camcorder
Image processor	DIGIC DV III
Minimum illumination	0.7 lx
Product color	Black
Video resolutions	1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Maximum frame rate	50 fps
Video formats supported	MPEG2, MXF
Maximum video resolution	1920 x 1080 pixels
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	1
Battery capacity	- mAh
Battery life (max)	- h
Operating temperature (T-T)	-5 - 45 °C

Weight and Dimensions

Depth	268 mm
Width	139 mm
Height	191 mm
Weight	1120 g
