Canon XF100 User Manual

43
Recording Video
NOTES
• You can press the DISP. button to turn off most icons and displays.
• When the A icon appears next to the white balance, aperture value, gain or shutter speed, it indicates that the
setting is in auto mode.
1 Remaining battery time
• The icon shows a rough estimate of the remaining charge as a percentage of the full charge of the battery
pack. The remaining recording/playback time of the battery pack is displayed, in minutes, next to the
icon.
• P  Q  R  S  U (in red).
When U is displayed, replace the battery pack with a fully charged one.
• Depending on the conditions under which the camcorder and the battery pack are used, the actual
battery charge may not be indicated accurately.
3 Recording operation
14 Conversion lens
• When the optional WD-H58W Wide-converter is attached to the camcorder, the Z icon will appear.
When the optional TL-H58 Tele-converter is attached, the W icon will appear.
38 CF card status/available recording time
• The following indicates the CF card status.
j/l Can record on CF card
k/m No CF card or cannot record on CF card
The CF card selected for recording is indicated with a A mark.
N
REC Recording
STBY Record pause
NINT REC Interval recording
INT STBY (INT flashes) Interval record pause
NFRM REC Frame recording
NFRM STBY Frame record pause (after starting recording)
FRM STBY (FRM flashes) Frame record pause (before starting recording)
NS&F REC Slow & fast motion recording
S&F STBY Slow & fast motion record pause
NPRE REC Pre-recording (after pressing the START/STOP button)
PRE REC STBY Pre-recording (before pressing the START/STOP button)
COPY

Canon XF100 Specifications

General

Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/3 \
Effective megapixels (movie)	2.07 MP
Filter size	58 mm
Digital zoom	6 x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	4.25 - 42.5 mm
Interchangeable lens	-
Focal length (35mm film equivalent)	30.4 - 304 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	CF, SD, SDHC, SDXC
Maximum memory card size	32 GB
Internal storage capacity	- GB
Focus adjustment	Auto/Manual
Scene modes	Backlight, Spotlight
Light exposure modes	Auto
Camera shutter speed	1/3 - 1/2000 s
Display diagonal	3.5 \
Viewfinder resolution	260000 pixels
Viewfinder screen size	0.24 \
Photo effects	Black&White
Camcorder type	Handheld camcorder
Image processor	DIGIC DV III
Minimum illumination	0.7 lx
Product color	Black
Video resolutions	1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Maximum frame rate	50 fps
Video formats supported	MPEG2, MXF
Maximum video resolution	1920 x 1080 pixels
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	1
Battery capacity	- mAh
Battery life (max)	- h
Operating temperature (T-T)	-5 - 45 °C

Weight and Dimensions

Depth	268 mm
Width	139 mm
Height	191 mm
Weight	1120 g
