Canon XF100 User Manual

89
Special Recording Modes
3 Press the START/STOP button to begin recording.
• The tally lamps illuminate.
• [PRE REC STBY] changes to [N PRE REC] while recording.
4 Press the START/STOP button again to stop recording.
• The camcorder records the clip, including approximately 3 seconds of video and audio recorded before the
START/STOP button was pressed.
• The tally lamps go out and [PRE REC STBY] appears at the top of the screen.
NOTES
• You can use only one special recording mode at a time.
• Pre-recording mode will be deactivated if the special recording mode is changed or turned off. It will be
deactivated also if you change the video configuration.
• During pre-recording mode, the time code will be recorded with the running mode (0 69) set to [Free Run],
regardless of the previous setting. Alternatively, you can use an external time code signal (b only). When
the time code is recorded, it will include the 3 seconds before the START/STOP button was pressed. When
special recording mode is deactivated, the running mode will return to its previous setting.
COPY

Canon XF100 Specifications

General

Sensor type	CMOS
Total megapixels	2.37 MP
Optical sensor size	1/3 \
Effective megapixels (movie)	2.07 MP
Filter size	58 mm
Digital zoom	6 x
Optical zoom	10 x
Image stabilizer	Yes
Focal length range	4.25 - 42.5 mm
Interchangeable lens	-
Focal length (35mm film equivalent)	30.4 - 304 mm
Memory slots	2
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	CF, SD, SDHC, SDXC
Maximum memory card size	32 GB
Internal storage capacity	- GB
Focus adjustment	Auto/Manual
Scene modes	Backlight, Spotlight
Light exposure modes	Auto
Camera shutter speed	1/3 - 1/2000 s
Display diagonal	3.5 \
Viewfinder resolution	260000 pixels
Viewfinder screen size	0.24 \
Photo effects	Black&White
Camcorder type	Handheld camcorder
Image processor	DIGIC DV III
Minimum illumination	0.7 lx
Product color	Black
Video resolutions	1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Maximum frame rate	50 fps
Video formats supported	MPEG2, MXF
Maximum video resolution	1920 x 1080 pixels
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	1
Battery capacity	- mAh
Battery life (max)	- h
Operating temperature (T-T)	-5 - 45 °C

Weight and Dimensions

Depth	268 mm
Width	139 mm
Height	191 mm
Weight	1120 g
