Canton Smart Connect 5.1 Quick Guide

46
English
USING AirPlay 2 TECHNOLOGY
With Apple AirPlay technology, you can play audio content over the wireless
network (WLAN) using your Smart Connect 5.1.
Additionally, AirPlay 2 technology offers you the possibility to play your
content on several amplifiers and/or loudspeakers synchronously.
Connecting the Smart Connect 5.1 to the WLAN (WiFi network) via iPhone,
iPad or iPod touch
To connect your Smart Connect 5.1 to your WLAN (WiFi network) via iPhone,
iPad or iPod touch, please proceed as follows:
1
Connect your Smart Connect 5.1 to the power outlet and wait until the
display shows [NET] followed by [SET].
2
On your iPhone, iPad or iPod touch, select „Settings“ and then „Wi-Fi“
(WLAN).
3
Under the menu item „SET UP NEW AIRPLAY SPEAKER“ select the Smart
Connect 5.1 as the device to be installed.
4
The „AirPlay Config...“ window opens.
a. Under „Network“ select the network to which you want to
connect the Smart Connect 5.1.
b. Under “Speaker name” enter the name (synonym) you want to
assign to the Connect 5.1.
c. Optionally, you can assign a password under „SPEAKER
PASSWORD“.
d. Select the function „Next“ and wait (approx. 30 seconds) until the
Smart Connect 5.1 shows [WIF] / [CON] in the display.
5
Finalize the registration process in the „Configuration finished“ window
that opens by pressing the „Done“ button. The Smart Connect 5.1 is now
connected to your WLAN (WiFi network) and ready for use.

Canton Smart Connect 5.1 Specifications

General

Control type	Touch
Product color	Black
Audio decoders	DTS, Dolby Digital
Built-in display	Yes
Bluetooth version	4.0
Display technology	LED
Cables included	AC
Power consumption (economy mode)	0.46 W
HDMI input ports quantity	3
HDMI output ports quantity	1

Weight and Dimensions

Depth	140 mm
Width	245 mm
Height	52 mm
Weight	1230 g
