OTHER SPECIFICATIONS
storage conditions -40T70 °C, 90% rH non-condensing
operating conditions -25T60 °C, 90% rH non-condensing
index of protection IP20, IP40 front panel only on the versions without ultracap module
environmental pollution 2
class according to protection against electric shock to be integrated into Class 1 and/or 2 appliances in the versions
without valve driver, Class 1 in versions with valve driver.
PTI of the insulating materials PCB: PTI250; insulation material: PTI 175
period of stress across the insulating parts long
type of action 1C; 1Y for SSR versions
type of disconnection or microswitching microswitching
category of resistance to heat and re category D (UL94 - V2)
immunity against voltage surges overvoltage category: II for all I/Os except for the high voltage digi-
tal outputs and digital inputs (class II circuits), which are category I
ageing characteristics (operating hours) 80,000
no. of automatic operating cycles 100,000 (EN 60730-1); 30,000 (UL 873)
software class and structure Class A
category of immunity to voltage surges (IEC EN 61000-4-5) Category 3
The device is not designed to be hand-held when powered.
Product certi cations
Electrical safety
EN 60730-1, EN 60730-2, UL60730
Electromagnetic compatibility Versions without valve driver: EN 61000-6-1, EN 61000-6-2, EN 61000-6-2/EC, EN 61000-6-2/IS1,
EN 61000-6-3, EN 61000-6-4; EN 55014-1, EN 55014-2, EN 55014-2/EC, EN 55014-2/A1,
EN 55014-2/IS1, EN 55014-2/A2
Versions with valve driver, with or without ultracap module: EN 61000-6-1, EN 61000-6-2, EN
61000-6-2/EC, EN 61000-6-2/IS1, EN61000-6-3, EN 61000-6-4
WARNINGS
• for applications subject to considerable vibrations (1.5 mm pk-pk 10/55 Hz), secure the cables connected to the pCO
5
around 3
cm from the connectors using clamps;
• cables longer then 10 m, excepted the cables for relays and 230 Vac digital inputs, must be shielded with shield connected to
the ground;
• in residential environments (EN55014), in the versions without valve driver the connection cable between the pCO
5
, the
terminal and the other serial boards must be shielded and earthed at both ends;
• the device must be installed according to the standards and legislation in force in the country where it is used;
• for safety reasons the equipment must be housed inside an electrical panel, so that the only accessible part is the display and
the keypad;
• all the extra low voltage connections (analogue and 24 Vac/Vdc digital inputs, analogue outputs, serial bus connections, power
supplies) must have reinforced or double insulation from the mains network;
• in the event of malfunctions, do not attempt to repair the device, but rather contact the CAREL service centre;
• make sure that the temperature inside the panel where the pCO
5
is installed does not exceed the operating conditions
ACCESSORIES
PCOS00AKY0 pCO Sistema smart key
0907877AXX external ferrite for pCO
5
power cable
S90CONN002 pGD terminal connection cable L= 0.8 m
S90CONN000 pGD terminal connection cable L= 1.5 m
S90CONN001 pGD terminal connection cable L= 3 m
