50
9.5 Compressor Protection and Slide Valve Capacity Control Kits
NOTES:
1. One Compressor Protection Module package required per com-
pressor.
2. The interface cable is required to connect/configure the included
module to a PC. The cable is also required for Field Service to
read information from the module.
9.6 Service Valves
9.6.1 Suction/Discharge Service Valve Package
Flanged Union, Solder Type, Cast Iron Valve Body
LEGEND
D — Discharge
S — Suction
9.7 Motor Protection Devices
One motor overload is required per compressor. The overload follows a 958-trip curve
Installation instruction are provided with the overload part.
PART NUMBER DESCRIPTION WEIGHT (LBS) APPLICATION
6BSB000929 High Temperature Controller Kit 5 R-134a, R-513A, R-1234ze
6BSB000930 Low/Medium Temperature Controller 5
R-404A, R-407A, R-407C, R-407F,
R-507A,
R-448A, R-449A
USB-L Interface Cable 1 All
CARLYLE PART
NUMBER
NOMINAL TUBE
SIZE (in.)
COMPRESSOR USAGE
TS TT TU
06TT660064
2
5
/
8
D
06TT660065
3
1
/
8
S D
06TT660066
4
1
/
8
S D
PART NUMBER QUANTITY/PACKAGE WEIGHT (lb) CURRENT (AMPS)
06EA907185
1 2 10-40
06EA907186
1 2 25-100
06EA907187
1 2 50-200
