COMBINATION RATINGS
Unit
S i z e ---
Voltage,
Series
Indoor Model
Cooling
Capacity
ARI Standard Ratings
Cooling Heating
Furnace Model
Factory
Enhance
Standard
Rating
SEER
TDR
EER
High Temp Low Temp
HSPF
E
Capacity
E
COP
H
Capacity
H
COP
18---32
*FY4ANF018 17,100 TDR&TXV 13.00 10.50 18,000 3.38 10,700 2.20 7.7
FF1ENP018 17,100 TDR&TXV 13.00 10.50 18,000 3.40 10,700 2.22 7.7
FF1ENP024 17,200 TDR&TXV 13.20 10.80 17,600 3.40 10,700 2.24 7.7
FV4BNF002 17,500 TDR&TXV 15.00 12.00 16,800 3.62 10,100 2.38 8.2
FX4CNF018 17,400 TDR&TXV 14.50 11.70 17,700 3.60 10,300 2.34 8.0
FX4CNF024 17,600 TDR&TXV 14.50 12.00 17,300 3.62 10,300 2.38 8.2
FY4ANF024 17,100 TDR&TXV 13.00 10.50 18,000 3.40 10,700 2.22 7.7
CAP**1814A** 17,000 TDR&TXV 14.00 11.50 17,100 3.36 10,000 2.26 7.7 58CV(A,X)070---12
CAP**1814A** 17,100 TXV 13.00 10.50 18,000 3.34 10,600 2.20 7.7
CAP**2414A** 17,200 TDR&TXV 14.50 11.70 17,300 3.50 10,100 2.32 7.8 58CV(A,X)070---12
CAP**2414A** 17,300 TXV 13.20 10.80 18,000 3.48 10,700 2.26 7.8
CAP**2417A** 17,300 TDR&TXV 14.50 12.00 17,400 3.54 10,100 2.34 7.9 58CV(A,X)090---16
CAP**2417A** 17,200 TDR&TXV 14.50 12.00 17,400 3.52 10,100 2.32 7.8 58MVB060---14
CAP**2417A** 17,300 TXV 13.20 10.80 18,000 3.48 10,700 2.26 7.8
CNPF*2418A** 17,300 TXV 13.20 10.80 18,000 3.54 10,800 2.28 7.9
CNPH*2417A** 17,200 TDR&TXV 14.50 11.70 17,400 3.54 10,100 2.34 7.9 58CV(A,X)070---12
CNPH*2417A** 17,200 TDR&TXV 14.50 12.00 17,500 3.58 10,100 2.34 7.9 58CV(A,X)090---16
CNPH*2417A** 17,200 TDR&TXV 14.50 11.70 17,400 3.56 10,100 2.34 7.9 58MVB040---14
CNPH*2417A** 17,200 TDR&TXV 14.50 11.70 17,400 3.56 10,100 2.34 7.9 58MVB060---14
CNPH*2417A** 17,200 TDR&TXV 14.50 11.70 17,500 3.58 10,100 2.34 7.9 58MVB080---14
CNPH*2417A** 17,300 TXV 13.20 10.80 18,000 3.54 10,800 2.28 7.9
CNPV*1814A** 17,100 TDR&TXV 14.50 11.70 17,400 3.48 10,100 2.30 7.8 58CV(A,X)070---12
CNPV*1814A** 17,200 TXV 13.00 10.50 18,000 3.48 10,700 2.26 7.8
CNPV*2414A** 17,200 TDR&TXV 14.50 11.70 17,400 3.54 10,100 2.34 7.9 58CV(A,X)070---12
CNPV*2414A** 17,300 TXV 13.20 10.80 18,000 3.54 10,800 2.26 7.8
CNPV*2417A** 17,200 TDR&TXV 14.50 12.00 17,500 3.58 10,100 2.34 7.9 58CV(A,X)090---16
CNPV*2417A** 17,300 TDR&TXV 14.50 11.70 17,400 3.56 10,100 2.34 7.9 58MVB060---14
CNPV*2417A** 17,300 TXV 13.20 10.80 18,000 3.54 10,800 2.28 7.9
CSPH*2412A* * 17,300 TDR&TXV 14.50 12.00 17,400 3.52 10,100 2.32 7.9 58CV(A,X)070---12
CSPH*2412A* * 17,400 TDR&TXV 14.50 12.00 17,500 3.56 10,100 2.34 7.9 58CV(A,X)090---16
CSPH*2412A* * 17,400 TDR&TXV 14.50 12.00 17,400 3.54 10,100 2.34 7.9 58MVB040 ---14
CSPH*2412A* * 17,400 TDR&TXV 14.50 12.00 17,400 3.54 10,100 2.34 7.9 58MVB060 ---14
CSPH*2412A* * 17,400 TDR&TXV 14.50 12.00 17,500 3.56 10,100 2.34 7.9 58MVB080 ---14
24---31
*FY4ANF024 22,600 TDR&TXV 13.00 10.50 24,000 3.54 15,000 2.48 8.2
FF1ENP024 22,800 TDR&TXV 13.00 10.70 24,000 3.56 15,200 2.46 8.2
FF1ENP030 22,800 TDR&TXV 13.00 10.40 24,200 3.56 15,100 2.48 8.0
FV4BNF002 23,200 TDR&TXV 14.00 11.70 23,200 3.80 14,400 2.66 8.5
FV4BNF003 23,400 TDR&TXV 14.00 12.00 23,000 3.78 14,300 2.66 8.5
FX4CNF024 23,000 TDR&TXV 14.00 11.40 23,800 3.72 14,600 2.60 8.3
FX4CNF030 23,400 TDR&TXV 14.00 11.70 23,600 3.84 14,600 2.66 8.5
FY4ANF030 23,000 TDR&TXV 13.20 10.60 24,000 3.64 15,100 2.52 8.4
CAP**2414A** 22,600 TDR&TXV 14.00 11.50 23,400 3.62 14,300 2.58 8.3 58CV(A,X)070---12
CAP**2414A** 22,800 TXV 13.00 10.50 24,400 3.60 15,100 2.50 8.3
CAP**2417A** 22,800 TDR&TXV 14.00 11.70 23,400 3.66 14,300 2.60 8.4 58CV(A,X)090---16
CAP**2417A** 22,800 TDR&TXV 14.00 11.70 23,400 3.64 14,300 2.58 8.4 58MVB060---14
CAP**2417A** 22,800 TXV 13.00 10.50 24,400 3.60 15,100 2.50 8.3
CAP**3014A** 23,000 TDR&TXV 14.00 11.70 23,000 3.64 14,400 2.60 8.4 58CV(A,X)070---12
CAP**3014A** 23,000 TXV 13.00 10.60 23,400 3.56 15,200 2.52 8.3
CAP**3017A** 23,000 TDR&TXV 14.00 11.70 23,000 3.68 14,300 2.62 8.5 58CV(A,X)090---16
CAP**3017A** 23,000 TDR&TXV 14.00 11.70 23,000 3.68 14,300 2.62 8.5 58MVB060---14
CAP**3017A** 23,000 TXV 13.00 10.60 23,400 3.56 15,200 2.52 8.3
CNPF*2418A** 22,800 TXV 13.00 10.50 24,400 3.68 15,200 2.52 8.5
CNPH*2417A** 22,600 TDR&TXV 14.00 11.50 23,600 3.68 14,400 2.58 8.4 58CV(A,X)070---12
Seenoteonpg.17
