ELECTRICAL DATA
U N I T S I Z E ---
VOLTAGE,
SERIES
V/PH
OPER VOLTS* COMPR FAN
MCA
MIN WIRE
SIZE{
MIN
WIRE
SIZE{
MAX
LENGTH
(ft.)}
MAX
LENGTH
(ft.)}
MAX FUSE**
or CKT BRK
AMPS
MAX MIN LRA RLA FLA 60° C 75° C 60° C 75° C
18---32
208--- 230/1 253 197
48 9.0 0.75 11.9 14 14 66 62 20
24---31 58 12.8 0.75 16.8 14 14 47 45 25
30---31 77 16.5 0.75 21.4 12 12 58 56 30
36---31 79 16.7 1.4 22.2 12 12 56 54 35
42---31 109 19.9 1.2 26.0 10 10 77 73 40
48---31 117 27.3 1.2 35.4 8 8 88 84 50
60---31 134 26.3 1.2 34.1 8 8 91 87 50
* Permissible limits of the voltage range at which the unit will operate satisfactorily
{ If wire is applied at ambient greater than 30_C(86_F), consult table 310---16 of the NE C (ANSI/NFPA 70). The ampacity of n on ---metallic---shea th ed cable
(NM), trade name ROMEX, shall be that of 60_C ( 140_F) conditions, per the NEC (ANSI/NFPA 70) Article 336---26. If other tha n uncoated (no ---pla ted), 60 or
75_C (140 or 167_F) insulation, copper wire (solid wire for 10 A WG or smaller, stranded wire for larger than 10 AWG) is used, consult applicable tables of
the NE C (ANSI/NFPA 70).
} Length shown is as measured 1 way along wire path between unit and service panel for voltage drop not to exceed 2%.
* * T i m e --- D e l a y f u s e .
FLA --- F u l l L o a d Am p s
LRA --- L o ck e d R ot o r A m p s
M C A --- Minimum Circuit Amps
RLA --- RatedLoadAmps
NOTE: Control circuit is 24--- V on all units and requires external power source. Copper wire must be used from service disconnect to unit.
All motors/compressors contain internal overload protection.
SOUND POWER
U N I T S I Z E ---
VOLTAGE, SERIES
STANDARD
RATING
(dBA)
TYPICAL OCTAVE BAND SPECTRUM (dB, without tone adjustment)
125 250 500 1000 2000 4000 8000
18---32 76 56.5 64.5 70 71 69 65 60.5
24---31 75 54.5 64 69 69.5 67.5 64 58
30---31 74 52 62.5 66.5 68.5 65 63.5 59
36---31 76 60 64 69.5 70 68.5 65.5 60.5
42---31 77 55.5 60 63.5 71.5 65 62.5 59
48---31 78 57 64 68 74 67 63 58.5
60---31 76 58.5 63 68 70.5 66.5 64.5 59.5
SOUND POWER WIT H SOUND SHIELD
U N I T S I Z E ---
VOLTAGE, SERIES
STANDARD
RATING
(dBA)
TYPICAL OCTAVE BAND SPECTRUM (dB, without tone adjustment)
125 250 500 1000 2000 4000 8000
18---32 75 56.0 64.5 69.5 70.5 68.5 65.0 59.5
24---31 74 54.0 63.5 69.0 69.0 67.5 63.5 57.5
30---31 74 51.5 62.0 66.5 67.5 64.5 62.0 57.5
36---31 76 58.5 63.5 69.5 70.5 69.0 65.5 60.5
42---31 75 55.0 60.5 63.5 69.0 64.5 61.5 56.0
48---31 75 57.5 63.0 67.5 71.5 65.5 60.5 54.5
60---31 75 58.5 62.5 67.5 69.0 64.5 61.5 56.0
CHARGING SUBCOOLING (TXV--TYPE EXPANSION DEVICE)
UNIT SIZE --- VOLTAGE, SERIES REQUIRED SUBCOOLING _F(_C) OUTDOOR HEATING PISTON #
18---32 10 (5.6) 42
24---31 12 (6.7) 46
30---31 11 (6.1) 55
36---31 10 (5.6) 57
42---31 11 (6.1) 61
48---31 11 (6.1) 61
60---31 12 (6.7) 76
25HBA3
