HEAT PUMP HEATI NG PERFORMANCE
INDOOR AIR
OUTDOOR COIL ENTERING AIR TEMPERATURES _F(_C)
--- 3 ( --- 1 9 . 4) 7 ( ---13.9) 17 ( ---8.3) 27 (---2.8) 37 (2.8) 47 (8.3) 57 (13.9) 67 (19.4)
EDB CFM
Capacity MBtuh
Tota l
Sys.
KW†
Capacity MBtuh
Tota l
Sys.
KW†
Capacity MBtuh
Tota l
Sys.
KW†
Capacity MBtuh
Tota l
Sys.
KW†
Capacity MBtuh
Tota l
Sys.
KW†
Capacity MBtuh
Tota l
Sys.
KW†
Capacity MBtuh
Tota l
Sys.
KW†
Capacity MBtuh
Tota l
Sys.
KW†
Tota l Integ* Tota l Integ* To tal Integ* To tal Integ* To tal Integ* To t al Integ* To tal Integ* To tal Integ*
25HBA318A32 Outdoor Section With FY4ANF018 Indoor Section
65
525 6.43 5.92 1.23 8.38 7.70 1.28 10.46 9.53 1.33 12.69 11.27 1.38 15.19 13.83 1.44 17.98 17.98 1.52 20.66 20.66 1.59 23.20 23.20 1.67 600 6.59 6.06 1.25 8.56 7.87 1.29 10.68 9.74 1.33 12.92 11.48 1.37 15.51 14.11 1.43 18.25 18.25 1.49 20.72 20.72 1.55 23.20 23.20 1.61 675 6.74 6.20 1.27 8.72 8.01 1.31 10.85 9.89 1.34 13.13 11.66 1.38 15.74 14.33 1.43 18.51 18.51 1.48 20.74 20.74 1.53 23.06 23.06 1.58
70
525 6.09 5.60 1.27 8.12 7.46 1.33 10.19 9.29 1.39 12.41 11.02 1.44 14.88 13.54 1.51 17.65 17.65 1.60 20.42 20.42 1.67 22.95 22.95 1.75 600 6.25 5.75 1.29 8.28 7.61 1.35 10.39 9.47 1.39 12.63 11.22 1.44 15.15 13.79 1.50 18.00 18.00 1.57 20.51 20.51 1.63 23.03 23.03 1.70 675 6.40 5.89 1.31 8.44 7.75 1.36 10.56 9.63 1.40 12.83 11.39 1.44 15.39 14.01 1.50 18.16 18.16 1.55 20.56 20.56 1.60 22.95 22.95 1.66
75
525 5.73 5.27 1.32 7.79 7.16 1.39 9.90 9.03 1.45 12.14 10.78 1.51 14.56 13.25 1.58 17.32 17.32 1.67 20.17 20.17 1.76 22.69 22.69 1.84 600 5.89 5.42 1.34 7.97 7.32 1.40 10.10 9.21 1.46 12.36 10.97 1.51 14.84 13.50 1.57 17.64 17.64 1.65 20.35 20.35 1.71 22.82 22.82 1.79 675 6.04 5.56 1.36 8.13 7.47 1.42 10.28 9.37 1.47 12.55 11.15 1.51 15.07 13.71 1.57 17.88 17.88 1.63 20.38 20.38 1.68 22.80 22.80 1.75
Heating Indoor Model Capacity Power Furnace Model
*FY4ANF018 1.00 1.00
CAP**1814A** 1.00 1.01 CAP**2414A** 1.00 0.97 CAP**2417A** 1.00 0.97
CNPF*2418A** 1.00 0.95
CNPH*2417A** 1.00 0.95
CNPV*1814A** 1.00 0.97 CNPV*2414A** 1.00 0.95 CNPV*2417A** 1.00 0.95
CSPH*2412A** 0.99 0.95
FF1ENP018 1.00 1.00 FF1ENP024 0.99 0.97 FV4BNF002 0.96 0.88
FX4CNF018 0.98 0.92 FX4CNF024 0.97 0.89
FY4ANF024 0.99 0.99
CAP**1814A** 0.95 0.96 58CV(A,X)070 ---12 CAP**2414A** 0.96 0.92 58CV(A,X)070 ---12
CNPH*2417A** 0.96 0.91 58CV(A,X)070---12
CNPV*1814A** 0.95 0.92 58CV(A,X)070---12 CNPV*2414A** 0.96 0.91 58CV(A,X)070---12
CSPH*2412A** 0.96 0.91 58CV(A,X)070---12
CAP**2417A** 0.96 0.91 58CV(A,X)090 ---16
CNPH*2417A** 0.96 0.91 58CV(A,X)090---16
CNPV*2417A** 0.96 0.90 58CV(A,X)090---16
CSPH*2412A** 0.96 0.90 58CV(A,X)090---16
CNPH*2417A** 0.96 0.91 58MVB040 ---14
CSPH*2412A** 0.96 0.91 58MVB040---14
CAP**2417A** 0.96 0.92 58MVB060 ---14
CNPH*2417A** 0.96 0.91 58MVB060 ---14
CNPV*2417A** 0.96 0.91 58MVB060---14
CSPH*2412A** 0.96 0.91 58MVB060---14
CNPH*2417A** 0.96 0.90 58MVB080 ---14
CSPH*2412A** 0.96 0.90 58MVB080---14
Seenoteonpg.31
