COMBINATION RATINGS
AHRI
Ref. No.
Model
Number
Coil Model Number
Furnace
Model Number
Cooling
Capacity
EER SEER
High Temp
HSPF
Low Temp
E
Capacity
E
COP
H
Capacity
H
COP
3699492 25HBC318(A,W)**30 †FY5BNF018 17,400 11.0 13.0 17,600 3.60 7.7 10,800 2.38
3699493 25HBC318(A,W)**30 FB4CNF018 17,400 11.0 13.0 17,400 3.72 7.7 10,500 2.44
3698297 25HBC318(A,W)**30 FB4CNF018+TXV 17,400 11.5 14.0 17,400 3.72 7.7 10,500 2.44
3699494 25HBC318(A,W)**30 FB4CNF024 17,400 11.0 13.2 17,400 3.72 7.7 10,500 2.44
3698298 25HBC318(A,W)**30 FB4CNF024+TXV 17,400 11.5 14.0 17,400 3.72 7.7 10,500 2.44
3698288 25HBC318(A,W)**30 FE4ANF002+UI 17,600 11.5 14.5 17,000 3.82 8.0 10,300 2.50
3698289 25HBC318(A,W)**30 FF1ENP019 17,200 11.5 14.0 17,200 3.70 7.8 10,500 2.44
3698290 25HBC318(A,W)**30 FF1ENP024 17,200 11.0 13.0 17,600 3.54 7.7 11,000 2.32
3698291 25HBC318(A,W)**30 FF1ENP025 17,600 12.0 14.5 17,200 3.82 8.0 10,500 2.50
3698292 25HBC318(A,W)**30 FF1ENP031 17,600 11.5 14.0 17,000 3.76 7.8 10,600 2.46
3698293 25HBC318(A,W)**30 FV4BNF002 17,600 11.5 14.5 17,000 3.82 8.0 10,300 2.50
3698294 25HBC318(A,W)**30 FV4CNF002 17,600 11.5 14.5 17,000 3.82 8.0 10,300 2.50
3698295 25HBC318(A,W)**30 FX4CNF018 17,200 11.5 14.0 17,200 3.72 7.8 10,500 2.44
3698296 25HBC318(A,W)**30 FX4CNF024 17,400 11.5 14.0 17,200 3.78 7.8 10,500 2.48
3698287 25HBC318(A,W)**30 FX4DN(B,F)031 17,600 11.5 14.0 17,000 3.76 7.8 10,700 2.48
3698285 25HBC318(A,W)**30 FX4DNF019 17,800 11.5 14.0 17,200 3.86 8.0 10,500 2.52
3698286 25HBC318(A,W)**30 FX4DNF025 17,800 11.5 14.0 17,000 3.86 8.0 10,500 2.50
3698299 25HBC318(A,W)**30 FY5BNF018+TXV 17,400 11.0 13.5 17,600 3.60 7.7 10,800 2.38
3699495 25HBC318(A,W)**30 FY5BNF024 17,400 11.0 13.0 17,200 3.62 7.7 10,800 2.38
3698300 25HBC318(A,W)**30 FY5BNF024+TXV 17,400 11.0 13.5 17,200 3.62 7.7 10,800 2.38
3698237 25HBC318(A,W)**30 CAP**1814A** 58CV(A,X)070---12 17,000 11.5 14.0 17,000 3.54 7.7 10,200 2.38
3698238 25HBC318(A,W)**30 CAP**1814A** 58PH*045---08 17,200 11.5 14.0 17,200 3.62 7.7 10,400 2.42
3698240 25HBC318(A,W)**30 CAP**2414A** 58CV(A,X)070---12 17,400 11.5 14.0 17,000 3.66 7.7 10,300 2.44
3698241 25HBC318(A,W)**30 CAP**2414A** 58PH*045---08 17,600 11.5 14.0 17,400 3.80 7.8 10,500 2.48
3698239 25HBC318(A,W)**30 CAP**2414A**+TDR 17,400 11.0 13.0 17,600 3.58 7.7 11,000 2.34
3698244 25HBC318(A,W)**30 CAP**2417A** 58CV(A,X)090---16 17,200 11.5 14.0 17,200 3.70 7.7 10,300 2.46
3698246 25HBC318(A,W)**30 CAP**2417A** 58ME(B,C)060---12 17,600 11.5 14.0 17,400 3.86 8.0 10,400 2.52
3698245 25HBC318(A,W)**30 CAP**2417A** 58MEB040---12 17,800 12.0 14.5 17,400 3.96 8.2 10,500 2.56
3698243 25HBC318(A,W)**30 CAP**2417A** 58MV(B,C)060---14 17,200 11.5 14.0 17,200 3.68 7.7 10,300 2.44
3699414 25HBC318(A,W)**30 CAP**2417A** 58UVB060---14 17,200 11.5 14.0 17,200 3.68 7.7 10,300 2.44
3698302 25HBC318(A,W)**30 CAP**2417A** 58VLR105--- 12 17,400 11.5 14.0 17,200 3.86 8.0 10,500 2.52
3698301 25HBC318(A,W)**30 CAP**2417A** 58VMR105---12 17,400 11.5 14.0 17,200 3.72 7.8 10,300 2.46
3698242 25HBC318(A,W)**30 CAP**2417A**+TDR 17,200 11.0 13.0 17,800 3.58 7.7 11,000 2.34
3698273 25HBC318(A,W)**30 CNPF*2418A**+TDR 17,400 11.0 13.0 17,800 3.62 7.7 11,000 2.36
3698266 25HBC318(A,W)**30 CNPH*2417A** 58CV(A,X)070---12 17,400 11.5 14.0 17,200 3.70 7.8 10,300 2.44
3698267 25HBC318(A,W)**30 CNPH*2417A** 58CV(A,X)090---16 17,400 11.5 14.0 17,200 3.72 7.8 10,300 2.46
3698271 25HBC318(A,W)**30 CNPH*2417A** 58HDV040--- ---12 17,800 11.5 14.0 17,800 3.90 8.0 10,900 2.50
3698272 25HBC318(A,W)**30 CNPH*2417A** 58HDV060--- ---12 17,800 11.5 14.0 17,800 3.90 8.0 10,800 2.50
3698270 25HBC318(A,W)**30 CNPH*2417A** 58ME(B,C)060---12 17,400 11.5 14.0 17,200 3.82 8.0 10,400 2.50
3698269 25HBC318(A,W)**30 CNPH*2417A** 58MEB040---12 17,800 11.5 14.0 17,400 3.90 8.0 10,500 2.54
3698264 25HBC318(A,W)**30 CNPH*2417A** 58MV(B,C)060---14 17,400 11.5 14.0 17,200 3.72 7.8 10,300 2.46
3698265 25HBC318(A,W)**30 CNPH*2417A** 58MV(B,C)080---14 17,000 11.5 14.0 17,000 3.70 7.8 10,300 2.44
3698263 25HBC318(A,W)**30 CNPH*2417A** 58MVB040---14 17,400 11.5 14.0 17,200 3.72 7.8 10,300 2.44
3698268 25HBC318(A,W)**30 CNPH*2417A** 58PH*045---08 17,600 11.5 14.0 17,200 3.80 8.0 10,500 2.48
3698308 25HBC318(A,W)**30 CNPH*2417A** 58VLR105--- 12 17,400 11.5 14.0 17,200 3.90 8.0 10,500 2.52
3698307 25HBC318(A,W)**30 CNPH*2417A** 58VMR105---12 17,400 11.5 14.0 17,200 3.76 7.8 10,400 2.46
3698262 25HBC318(A,W)**30 CNPH*2417A**+TDR 17,400 11.0 13.0 17,800 3.62 7.7 11,000 2.36
3698247 25HBC318(A,W)**30 CNPV*1814A** 58CV(A,X)070---12 17,200 11.5 14.0 17,200 3.64 7.7 10,300 2.42
3698248 25HBC318(A,W)**30 CNPV*1814A** 58PH*045---08 17,400 11.5 14.0 17,200 3.70 7.7 10,400 2.44
3698251 25HBC318(A,W)**30 CNPV*1917A** 58CV(A,X)090---16 17,400 11.5 14.0 17,200 3.78 7.8 10,300 2.48
3698253 25HBC318(A,W)**30 CNPV*1917A** 58ME(B,C)060---12 17,800 12.0 14.5 17,400 3.98 8.2 10,500 2.56
3698252 25HBC318(A,W)**30 CNPV*1917A** 58MEB040---12 17,800 12.0 14.5 17,400 4.06 8.2 10,600 2.58
3698250 25HBC318(A,W)**30 CNPV*1917A** 58MV(B,C)060---14 17,400 11.5 14.0 17,200 3.76 7.8 10,300 2.48
3699415 25HBC318(A,W)**30 CNPV*1917A** 58UVB060---14 17,400 11.5 14.0 17,200 3.76 7.8 10,300 2.48
3698304 25HBC318(A,W)**30 CNPV*1917A** 58VLR105---12 17,400 12.0 14.5 17,200 3.98 8.2 10,500 2.54
3698303 25HBC318(A,W)**30 CNPV*1917A** 58VMR105--- 12 17,400 11.5 14.0 17,200 3.82 7.8 10,400 2.50
3698249 25HBC318(A,W)**30 CNPV*1917A**+TDR 17,400 11.0 13.0 17,800 3.66 7.7 11,100 2.36
3698255 25HBC318(A,W)**30 CNPV*2414A** 58CV(A,X)070---12 17,400 11.5 14.0 17,200 3.70 7.7 10,300 2.44
3698256 25HBC318(A,W)**30 CNPV*2414A** 58PH*045---08 17,400 11.5 14.0 17,200 3.80 8.0 10,500 2.48
3698254 25HBC318(A,W)**30 CNPV*2414A**+TDR 17,400 11.0 13.0 17,600 3.62 7.7 11,000 2.36
3698259 25HBC318(A,W)**30 CNPV*2417A** 58CV(A,X)090---16 17,400 11.5 14.0 17,200 3.72 7.7 10,300 2.46
3698261 25HBC318(A,W)**30 CNPV*2417A** 58ME(B,C)060---12 17,400 11.5 14.0 17,200 3.82 7.8 10,400 2.50
3698260 25HBC318(A,W)**30 CNPV*2417A** 58MEB040---12 17,800 11.5 14.0 17,400 3.90 8.0 10,500 2.54
3698258 25HBC318(A,W)**30 CNPV*2417A** 58MV(B,C)060---14 17,400 11.5 14.0 17,200 3.72 7.7 10,300 2.46
3699416 25HBC318(A,W)**30 CNPV*2417A** 58UVB060---14 17,400 11.5 14.0 17,200 3.72 7.7 10,300 2.46
3698306 25HBC318(A,W)**30 CNPV*2417A** 58VLR105---12 17,400 11.5 14.0 17,200 3.90 8.0 10,500 2.52
3698305 25HBC318(A,W)**30 CNPV*2417A** 58VMR105--- 12 17,400 11.5 14.0 17,200 3.76 7.8 10,400 2.46
3698257 25HBC318(A,W)**30 CNPV*2417A**+TDR 17,400 11.0 13.0 17,800 3.62 7.7 11,000 2.36
3698278 25HBC318(A,W)**30 CSPH*2412A** 58CV(A,X)070---12 17,400 11.5 14.0 17,200 3.70 7.8 10,300 2.44
3698279 25HBC318(A,W)**30 CSPH*2412A** 58CV(A,X)090---16 17,400 11.5 14.0 17,200 3.72 7.8 10,400 2.46
3698283 25HBC318(A,W)**30 CSPH*2412A** 58HDV040--- ---12 17,800 11.5 14.0 17,400 3.86 8.0 10,800 2.50
3698284 25HBC318(A,W)**30 CSPH*2412A** 58HDV060--- ---12 17,800 11.5 14.0 17,400 3.86 8.0 10,800 2.50
3698282 25HBC318(A,W)**30 CSPH*2412A** 58ME(B,C)060---12 17,800 11.5 14.0 17,000 3.76 7.8 10,300 2.48
3698281 25HBC318(A,W)**30 CSPH*2412A** 58MEB040---12 17,800 11.5 14.0 17,200 3.86 7.8 10,500 2.52
3698276 25HBC318(A,W)**30 CSPH*2412A** 58MV(B,C)060---14 17,400 11.5 14.0 17,200 3.72 7.8 10,300 2.44
3698277 25HBC318(A,W)**30 CSPH*2412A** 58MV(B,C)080---14 17,400 11.5 14.0 17,000 3.70 7.8 10,300 2.44
3698275 25HBC318(A,W)**30 CSPH*2412A** 58MVB040---14 17,400 11.5 14.0 17,200 3.72 7.8 10,400 2.44
3698280 25HBC318(A,W)**30 CSPH*2412A** 58PH*045---08 17,600 11.5 14.0 17,200 3.78 7.8 10,500 2.48
3698310 25HBC318(A,W)**30 CSPH*2412A** 58VLR105---12 17,400 11.5 14.0 17,200 3.90 8.0 10,500 2.52
3698309 25HBC318(A,W)**30 CSPH*2412A** 58VMR105---12 17,400 11.5 14.0 17,200 3.76 7.8 10,400 2.46
3698274 25HBC318(A,W)**30 CSPH*2412A**+TDR 17,400 11.0 13.0 17,800 3.62 7.7 11,000 2.36
3699484 25HBC324(A,W)**30 †FY5BNF024 23,000 11.0 13.0 22,800 3.60 7.7 13,700 2.40
3699485 25HBC324(A,W)**30 FB4CNF024 23,000 11.0 13.0 22,600 3.58 7.7 13,600 2.38
3698450 25HBC324(A,W)**30 FB4CNF024+TXV 23,000 11.0 13.2 22,600 3.58 7.7 13,600 2.38
3699486 25HBC324(A,W)**30 FB4CNF030 23,000 11.5 13.2 22,400 3.74 7.8 13,600 2.46
3698451 25HBC324(A,W)**30 FB4CNF030+TXV 23,000 11.5 13.5 22,400 3.72 7.8 13,600 2.46
