HEAT PUMP HEATING PERFORMANCE
INDOOR AIR
OUTDOOR COIL ENTERING AIR TEMPERATURES ° F (° C)
--- 3 ( --- 1 9 . 4 ) 7 (---13.9) 17 ( ---8.3) 27 ( ---2.8) 37 (2.8) 47 (8.3) 57 (13.9) 67 (19.4)
EDB
°F (°C)
CFM
Capacity MBtuh
Tot a l
Syst.
KW†
Capacity MBtuh
Tot a l
Syst.
KW†
Capacity MBtuh
Tot a l
Syst.
KW†
Capacity MBtuh
Tot a l
Syst.
KW†
Capacity MBtuh
Tot a l
Syst.
KW†
Capacity MBtuh
Tot a l
Syst.
KW†
Capacity MBtuh
Tot a l
Syst.
KW†
Capacity MBtuh
Tot a l
Syst.
KW†
Tot a l Integ* Tot a l Integ* To ta l Integ* Tota l Integ* To ta l Integ* Tota l Integ* Tota l Integ* To t a l Integ*
25HBC318(A,W)**30 Outdoor Section With FY5BNF018 Indoor Section
65 (18.3)
525 5.41 4.98 1.10 7.54 6.93 1.15 10.08 9.19 1.21 12.38 11.00 1.26 14.90 13.56 1.32 17.69 17.69 1.39 19.98 19.98 1.45 22.14 22.14 1.52 600 5.51 5.07 1.11 7.66 7.04 1.16 10.23 9.33 1.21 12.56 11.15 1.25 15.13 13.77 1.31 17.82 17.82 1.37 19.82 19.82 1.41 21.62 21.62 1.46 675 5.62 5.17 1.13 7.78 7.15 1.17 10.36 9.45 1.22 12.71 11.29 1.25 15.32 13.94 1.30 17.80 17.80 1.35 19.61 19.61 1.39 20.95 20.95 1.42
70 (21.1)
525 5.15 4.74 1.15 7.28 6.69 1.20 9.58 8.73 1.26 12.15 10.79 1.32 14.63 13.31 1.38 17.39 17.39 1.46 19.80 19.80 1.52 22.05 22.05 1.60 600 5.26 4.84 1.16 7.41 6.81 1.21 9.75 8.89 1.26 12.33 10.95 1.31 14.85 13.51 1.37 17.60 17.60 1.43 19.72 19.72 1.48 21.64 21.64 1.54 675 5.36 4.93 1.17 7.53 6.92 1.22 9.93 9.05 1.27 12.48 11.08 1.31 15.04 13.69 1.36 17.67 17.67 1.42 19.54 19.54 1.46 21.11 21.11 1.50
75 (23.9)
525 4.87 4.48 1.19 6.99 6.42 1.25 9.27 8.45 1.31 11.92 10.59 1.38 14.34 13.05 1.44 17.07 17.07 1.53 19.60 19.60 1.60 21.88 21.88 1.67 600 4.99 4.59 1.21 7.13 6.55 1.26 9.44 8.61 1.31 12.09 10.74 1.37 14.56 13.25 1.43 17.33 17.33 1.50 19.57 19.57 1.56 21.60 21.60 1.62 675 5.09 4.68 1.22 7.26 6.67 1.27 9.59 8.75 1.32 12.25 10.88 1.37 14.75 13.43 1.42 17.47 17.47 1.48 19.47 19.47 1.53 21.18 21.18 1.58
HEATING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
*FY5BNF018 1.00 1.00
FB4CNF018 0.99 0.96 FB4CNF018 0.99 0.96 FB4CNF024 0.99 0.96 FB4CNF024 0.99 0.96
FE4ANF002 0.97 0.91 FF1ENP019 0.98 0.95 FF1ENP024 1.00 1.02 FF1ENP025 0.98 0.92 FF1ENP031 0.97 0.92 FV4BNF002 0.97 0.91
FV4CNF002 0.97 0.91 FX4CNF018 0.98 0.95 FX4CNF024 0.98 0.93
FX4DN(B,F)031 0.97 0.93
FX4DNF019 0.98 0.91 FX4DNF025 0.97 0.90
FY5BNF018 1.00 1.00 FY5BNF024 0.98 0.97 FY5BNF024 0.98 0.97
CAP**2414A** 1.00 1.01 CAP**2417A** 1.01 1.02
CNPF*2418A** 1.01 1.01
CNPH*2417A** 1.01 1.01
CNPV*1917A** 1.01 0.99 CNPV*2414A** 1.00 0.99 CNPV*2417A** 1.01 1.01
CSPH*2412A** 1.01 1.01
CAP**1814A** 0.97 0.99 58CV(A,X)070--- 12 CAP**2414A** 0.97 0.95 58CV(A,X)070--- 12
CNPH*2417A** 0.98 0.95 58CV(A,X)070--- 12
CNPV*1814A** 0.98 0.97 58CV(A,X)070--- 12 CNPV*2414A** 0.98 0.95 58CV(A,X)070--- 12
CSPH*2412A** 0.98 0.95 58CV(A,X)070--- 12
CAP**2417A** 0.98 0.95 58CV(A,X)090--- 16
CNPH*2417A** 0.98 0.94 58CV(A,X)090--- 16
CNPV*1917A** 0.98 0.93 58CV(A,X)090--- 16 CNPV*2417A** 0.98 0.94 58CV(A,X)090--- 16
CSPH*2412A** 0.98 0.94 58CV(A,X)090--- 16
CNPH*2417A** 1.01 0.93 58HDV040--- --- 12
CSPH*2412A** 0.99 0.92 58HDV040--- ---12
CNPH*2417A** 1.01 0.93 58HDV060--- --- 12
CSPH*2412A** 0.99 0.92 58HDV060--- ---12
CAP**2417A** 0.99 0.92 58ME(B,C)060--- 12
HEATING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
CNPH*2417A** 0.98 0.92 58ME(B,C)060--- 12
CNPV*1917A** 0.99 0.90 58ME(B,C)060--- 12 CNPV*2417A** 0.98 0.92 58ME(B,C)060--- 12
CSPH*2412A** 0.97 0.93 58ME(B,C)060--- 12
CAP**2417A** 0.99 0.90 58MEB040--- 12
CNPH*2417A** 0.99 0.91 58MEB040--- 12
CNPV*1917A** 0.99 0.88 58MEB040--- 12 CNPV*2417A** 0.99 0.91 58MEB040--- 12
CSPH*2412A** 0.98 0.91 58MEB040--- 12
CAP**2417A** 0.98 0.96 58MV(B,C)060--- 14
CNPH*2417A** 0.98 0.95 58MV(B,C)060---14
CNPV*1917A** 0.98 0.93 58MV(B,C)060--- 14 CNPV*2417A** 0.98 0.95 58MV(B,C)060--- 14
CSPH*2412A** 0.98 0.95 58MV(B,C)060--- 14
CNPH*2417A** 0.97 0.94 58MV(B,C)080---14
CSPH*2412A** 0.97 0.94 58MV(B,C)080--- 14
CNPH*2417A** 0.98 0.95 58MVB040--- 14
CSPH*2412A** 0.98 0.95 58MVB040--- 14
CAP**1814A** 0.98 0.97 58PH*045--- 08 CAP**2414A** 0.99 0.94 58PH*045--- 08
CNPH*2417A** 0.98 0.93 58PH*045---08
CNPV*1814A** 0.98 0.95 58PH*045--- 08 CNPV*2414A** 0.98 0.93 58PH*045--- 08
CSPH*2412A** 0.98 0.93 58PH*045--- 08
CAP**2417A** 0.98 0.91 58VLR105--- 12
CNPH*2417A** 0.98 0.90 58VLR105--- 12
CNPV*1917A** 0.98 0.89 58VLR105--- 12 CNPV*2417A** 0.98 0.90 58VLR105--- 12
CSPH*2412A** 0.98 0.90 58VLR105--- 12
CAP**2417A** 0.98 0.95 58VMR105--- 12
CNPH*2417A** 0.98 0.94 58VMR105--- 12
CNPV*1917A** 0.98 0.92 58VMR105--- 12 CNPV*2417A** 0.98 0.94 58VMR105--- 12
CSPH*2412A** 0.98 0.94 58VMR105--- 12
