Carrier 25HBC3 Series User Manual

14
COMBINATION RATINGS CONTINUED
AHRI
Ref. No.
Model
Number
Coil Model Number
Furnace
Model Number
Cooling
Capacity
EER SEER
High Temp
HSPF
Low Temp
E
Capacity
E
COP
H
Capacity
H
COP
3698440 25HBC324(A,W)**30 FE4AN(B,F)003+UI 23,000 11.5 14.0 22,000 3.72 8.0 13,200 2.48
3698439 25HBC324(A,W)**30 FE4ANF002+UI 23,000 11.5 14.0 22,200 3.72 8.0 13,300 2.46
3698441 25HBC324(A,W)**30 FF1ENP025 23,000 11.0 13.2 22,600 3.66 8.0 13,600 2.42
3698442 25HBC324(A,W)**30 FF1ENP031 23,000 11.5 13.5 22,600 3.64 8.0 13,700 2.42
3698443 25HBC324(A,W)**30 FF1ENP037 23,200 11.5 13.5 22,600 3.74 8.0 13,700 2.46
3698445 25HBC324(A,W)**30 FV4BN(B,F)003 23,000 11.5 14.0 22,000 3.72 8.0 13,200 2.48
3698444 25HBC324(A,W)**30 FV4BNF002 23,000 11.5 14.0 22,200 3.72 8.0 13,300 2.46
3698447 25HBC324(A,W)**30 FV4CN(B,F)003 23,000 11.5 14.0 22,000 3.72 8.0 13,200 2.48
3698446 25HBC324(A,W)**30 FV4CNF002 23,000 11.5 14.0 22,200 3.72 8.0 13,300 2.46
3698448 25HBC324(A,W)**30 FX4CNF024 22,800 11.0 13.2 22,400 3.64 8.0 13,600 2.42
3698449 25HBC324(A,W)**30 FX4CNF030 23,000 11.5 13.5 22,400 3.74 8.0 13,600 2.48
3698437 25HBC324(A,W)**30 FX4DN(B,F)031 23,000 11.5 13.5 22,600 3.74 8.0 13,800 2.46
3698438 25HBC324(A,W)**30 FX4DN(B,F)037 23,200 11.5 14.0 22,000 3.88 8.0 13,700 2.54
3698436 25HBC324(A,W)**30 FX4DNF025 23,200 11.5 14.0 22,600 3.72 8.0 13,600 2.46
3698452 25HBC324(A,W)**30 FY5BNF024+TXV 23,000 11.0 13.2 22,800 3.60 7.7 13,800 2.40
3698453 25HBC324(A,W)**30 FY5BNF030+TXV 22,800 11.0 13.2 22,600 3.66 7.8 13,900 2.40
3698311 25HBC324(A,W)**30 CAP**2414A** 58CV(A,X)070---12 22,800 11.0 13.5 22,000 3.58 7.7 13,200 2.40
3698312 25HBC324(A,W)**30 CAP**2414A** 58PH*045---08 23,000 11.0 13.5 22,400 3.64 7.8 13,400 2.42
3698314 25HBC324(A,W)**30 CAP**2417A** 58CV(A,X)090---16 22,800 11.5 14.0 22,000 3.62 8.0 13,200 2.42
3698316 25HBC324(A,W)**30 CAP**2417A** 58ME(B,C)060---12 23,000 11.5 14.0 22,400 3.76 8.0 13,500 2.48
3698317 25HBC324(A,W)**30 CAP**2417A** 58ME(B,C)080---12 23,000 11.5 14.0 22,400 3.74 8.0 13,400 2.48
3698315 25HBC324(A,W)**30 CAP**2417A** 58MEB040---12 23,000 11.5 14.0 22,400 3.76 8.0 13,400 2.48
3698313 25HBC324(A,W)**30 CAP**2417A** 58MV(B,C)060---14 23,000 11.5 14.0 22,200 3.70 8.0 13,400 2.46
3699417 25HBC324(A,W)**30 CAP**2417A** 58UVB060---14 23,000 11.5 14.0 22,200 3.70 8.0 13,400 2.46
3698455 25HBC324(A,W)**30 CAP**2417A** 58VLR105--- 12 22,800 11.5 13.5 22,000 3.68 8.0 13,300 2.44
3698454 25HBC324(A,W)**30 CAP**2417A** 58VMR105---12 22,800 11.5 13.5 22,000 3.60 7.8 13,200 2.40
3698318 25HBC324(A,W)**30 CAP**3014A** 58CV(A,X)070---12 22,800 11.0 13.5 22,000 3.60 8.0 13,300 2.42
3698319 25HBC324(A,W)**30 CAP**3014A** 58PH*045---08 23,000 11.0 13.5 22,400 3.68 8.0 13,500 2.44
3698321 25HBC324(A,W)**30 CAP**3017A** 58CV(A,X)090---16 22,800 11.5 14.0 22,000 3.66 8.0 13,200 2.44
3698323 25HBC324(A,W)**30 CAP**3017A** 58ME(B,C)060---12 23,000 11.5 14.0 22,400 3.82 8.0 13,600 2.52
3698324 25HBC324(A,W)**30 CAP**3017A** 58ME(B,C)080---12 23,000 11.5 14.0 22,400 3.78 8.0 13,500 2.50
3698322 25HBC324(A,W)**30 CAP**3017A** 58MEB040---12 23,000 11.5 14.0 22,400 3.82 8.0 13,500 2.52
3698320 25HBC324(A,W)**30 CAP**3017A** 58MV(B,C)060---14 23,000 11.5 14.0 22,200 3.72 8.0 13,400 2.48
3699418 25HBC324(A,W)**30 CAP**3017A** 58UVB060---14 23,000 11.5 14.0 22,200 3.72 8.0 13,400 2.48
3698457 25HBC324(A,W)**30 CAP**3017A** 58VLR105--- 12 22,800 11.5 13.5 22,000 3.70 8.0 13,400 2.46
3698456 25HBC324(A,W)**30 CAP**3017A** 58VMR105---12 22,800 11.5 13.5 22,000 3.62 7.8 13,200 2.42
3698350 25HBC324(A,W)**30 CNPH*2417A** 58CV(A,X)070---12 22,600 11.5 13.5 22,200 3.64 8.0 13,300 2.40
3698351 25HBC324(A,W)**30 CNPH*2417A** 58CV(A,X)090---16 22,800 11.5 13.5 22,200 3.68 8.0 13,300 2.42
3698352 25HBC324(A,W)**30 CNPH*2417A** 58CV(A,X)110---20 22,800 11.5 13.5 22,200 3.66 8.0 13,300 2.42
3698353 25HBC324(A,W)**30 CNPH*2417A** 58CV(A,X)135---22 22,800 11.5 13.5 22,200 3.66 8.0 13,300 2.42
3698354 25HBC324(A,W)**30 CNPH*2417A** 58CV(A,X)155---22 22,800 11.5 13.5 22,200 3.68 8.0 13,300 2.42
3698359 25HBC324(A,W)**30 CNPH*2417A** 58HDV040--- ---12 22,800 11.0 13.2 22,400 3.66 8.0 13,600 2.40
3698360 25HBC324(A,W)**30 CNPH*2417A** 58HDV060--- ---12 23,000 11.0 13.2 22,600 3.70 8.0 13,700 2.42
3698361 25HBC324(A,W)**30 CNPH*2417A** 58HDV080--- ---20 23,000 11.5 13.5 22,800 3.80 8.0 13,800 2.48
3698362 25HBC324(A,W)**30 CNPH*2417A** 58HDV100--- ---20 23,000 11.5 13.5 22,600 3.76 8.0 13,700 2.46
3698357 25HBC324(A,W)**30 CNPH*2417A** 58ME(B,C)060---12 23,000 11.5 13.5 22,400 3.76 8.0 13,500 2.46
3698358 25HBC324(A,W)**30 CNPH*2417A** 58ME(B,C)080---12 23,000 11.5 13.5 22,400 3.74 8.0 13,400 2.46
3698356 25HBC324(A,W)**30 CNPH*2417A** 58MEB040---12 23,000 11.5 13.5 22,400 3.76 8.0 13,400 2.46
3698345 25HBC324(A,W)**30 CNPH*2417A** 58MV(B,C)060---14 23,000 11.5 13.5 22,400 3.74 8.0 13,500 2.46
3698346 25HBC324(A,W)**30 CNPH*2417A** 58MV(B,C)080---14 22,800 11.5 13.5 22,200 3.64 8.0 13,300 2.42
3698347 25HBC324(A,W)**30 CNPH*2417A** 58MV(B,C)080---20 22,800 11.5 13.5 22,000 3.60 7.8 13,200 2.40
3698348 25HBC324(A,W)**30 CNPH*2417A** 58MV(B,C)100---20 22,800 11.5 13.5 22,200 3.66 8.0 13,300 2.42
3698349 25HBC324(A,W)**30 CNPH*2417A** 58MV(B,C)120---20 22,800 11.5 13.5 22,400 3.70 8.0 13,300 2.44
3698344 25HBC324(A,W)**30 CNPH*2417A** 58MVB040---14 22,800 11.5 13.5 22,200 3.66 8.0 13,300 2.42
3698355 25HBC324(A,W)**30 CNPH*2417A** 58PH*045---08 22,800 11.5 13.5 22,200 3.68 8.0 13,400 2.42
3698465 25HBC324(A,W)**30 CNPH*2417A** 58VLR105--- 12 22,800 11.5 13.5 22,000 3.72 8.0 13,400 2.44
3698464 25HBC324(A,W)**30 CNPH*2417A** 58VMR105---12 22,600 11.5 13.5 22,000 3.62 7.8 13,300 2.40
3698369 25HBC324(A,W)**30 CNPH*3017A** 58CV(A,X)070---12 22,800 11.5 13.5 22,200 3.62 8.0 13,200 2.42
3698370 25HBC324(A,W)**30 CNPH*3017A** 58CV(A,X)090---16 23,000 11.5 14.0 22,200 3.66 8.0 13,200 2.44
3698371 25HBC324(A,W)**30 CNPH*3017A** 58CV(A,X)110---20 23,000 11.5 13.5 22,200 3.66 8.0 13,300 2.44
3698372 25HBC324(A,W)**30 CNPH*3017A** 58CV(A,X)135---22 23,000 11.5 13.5 22,200 3.66 8.0 13,300 2.44
3698373 25HBC324(A,W)**30 CNPH*3017A** 58CV(A,X)155---22 23,000 11.5 13.5 22,200 3.66 8.0 13,200 2.44
3698378 25HBC324(A,W)**30 CNPH*3017A** 58HDV040--- ---12 23,000 11.5 13.5 22,600 3.68 8.0 13,700 2.44
3698379 25HBC324(A,W)**30 CNPH*3017A** 58HDV060--- ---12 23,000 11.5 13.5 22,600 3.76 8.0 13,800 2.48
3698380 25HBC324(A,W)**30 CNPH*3017A** 58HDV100--- ---20 23,000 11.5 13.5 22,600 3.86 8.0 13,800 2.52
3698376 25HBC324(A,W)**30 CNPH*3017A** 58ME(B,C)060---12 23,000 11.5 14.0 22,400 3.82 8.0 13,600 2.52
3698377 25HBC324(A,W)**30 CNPH*3017A** 58ME(B,C)080---12 23,000 11.5 14.0 22,400 3.78 8.0 13,500 2.50
3698375 25HBC324(A,W)**30 CNPH*3017A** 58MEB040---12 23,000 11.5 14.0 22,400 3.82 8.0 13,500 2.52
3698364 25HBC324(A,W)**30 CNPH*3017A** 58MV(B,C)060---14 23,000 11.5 14.0 22,400 3.74 8.0 13,400 2.48
3698365 25HBC324(A,W)**30 CNPH*3017A** 58MV(B,C)080---14 22,800 11.5 13.5 22,200 3.64 8.0 13,200 2.44
3698366 25HBC324(A,W)**30 CNPH*3017A** 58MV(B,C)080---20 22,800 11.5 13.5 22,000 3.58 8.0 13,100 2.40
3698367 25HBC324(A,W)**30 CNPH*3017A** 58MV(B,C)100---20 22,800 11.5 13.5 22,000 3.64 8.0 13,200 2.44
3698368 25HBC324(A,W)**30 CNPH*3017A** 58MV(B,C)120---20 23,000 11.5 14.0 22,200 3.68 8.0 13,300 2.46
3698363 25HBC324(A,W)**30 CNPH*3017A** 58MVB040---14 23,000 11.5 13.5 22,200 3.64 8.0 13,300 2.44
3698374 25HBC324(A,W)**30 CNPH*3017A** 58PH*045---08 23,000 11.5 13.5 22,400 3.70 8.0 13,500 2.46
3698467 25HBC324(A,W)**30 CNPH*3017A** 58VLR105--- 12 22,800 11.5 13.5 22,000 3.72 8.0 13,400 2.46
3698466 25HBC324(A,W)**30 CNPH*3017A** 58VMR105---12 22,800 11.5 13.5 22,000 3.62 7.8 13,200 2.42
3698387 25HBC324(A,W)**30 CNPH*3117A** 58CV(A,X)070---12 23,200 11.5 14.0 22,400 3.80 8.0 13,400 2.48
3698388 25HBC324(A,W)**30 CNPH*3117A** 58CV(A,X)090---16 23,200 11.5 14.0 22,200 3.84 8.0 13,300 2.50
3698389 25HBC324(A,W)**30 CNPH*3117A** 58CV(A,X)110---20 23,200 11.5 14.0 22,400 3.82 8.0 13,400 2.50
3698390 25HBC324(A,W)**30 CNPH*3117A** 58CV(A,X)135---22 23,200 11.5 14.0 22,200 3.84 8.0 13,400 2.50
3698391 25HBC324(A,W)**30 CNPH*3117A** 58CV(A,X)155---22 23,200 11.5 14.0 22,200 3.84 8.0 13,400 2.50
3698396 25HBC324(A,W)**30 CNPH*3117A** 58HDV040--- ---12 23,200 11.5 13.5 22,400 3.84 8.0 13,800 2.50
3698397 25HBC324(A,W)**30 CNPH*3117A** 58HDV060--- ---12 23,200 11.5 13.5 22,400 3.86 8.0 14,000 2.54
3698398 25HBC324(A,W)**30 CNPH*3117A** 58HDV100--- ---20 23,200 11.5 14.0 22,000 3.94 8.0 14,000 2.60
3698394 25HBC324(A,W)**30 CNPH*3117A** 58ME(B,C)060---12 23,200 12.0 14.5 22,200 3.96 8.2 13,800 2.60
3698395 25HBC324(A,W)**30 CNPH*3117A** 58ME(B,C)080---12 23,200 11.5 14.0 22,200 3.94 8.0 13,700 2.56
See notes on page 45
