3
Unit Weights
Standard Units with Accessory Tank
Single Pump Units with Accessory Tank
Dual Pump Units with Accessory Tank
Fig. 2 — Weight Distribution
30RAP
SIZE
POUNDS
30RAP
SIZE
KILOGRAMS
A B C D
Total
Weight
A B C D
Total
Weight
010 607 627 579 564 2377 010 275.2 284.3 262.8 255.8 1078.2
015 611 631 582 567 2391 015 277.4 286.1 263.8 257.1 1084.4
018 912 812 758 836 3318 018 413.6 368.5 343.6 379.3 1505.0
020 914 815 760 838 3326 020 414.5 369.5 344.5 380.2 1508.7
025 941 839 786 869 3435 025 427.0 380.5 356.4 394.4 1558.2
030 953 849 794 880 3476 030 432.3 385.0 360.3 399.0 1576.7
035 1742 1820 1503 1459 6524 035 790.2 825.5 681.8 661.8 2959.3
040 1794 1788 1480 1484 6546 040 813.9 810.9 671.4 673.1 2969.2
045 1766 1849 1516 1469 6599 045 800.9 838.5 687.5 666.4 2993.3
050 1823 1814 1491 1496 6624 050 826.7 823.0 676.4 678.4 3004.5
055 1834 1852 1527 1517 6730 055 831.9 840.1 692.7 688.0 3052.7
060 1836 1852 1528 1519 6736 060 833.0 840.3 693.2 689.0 3055.4
30RAP
SIZE
POUNDS
30RAP
SIZE
KILOGRAMS
A B C D
Total
Weight
A B C D
Total
Weight
010 633 682 632 592 2539 010 287.4 309.5 286.5 268.6 1151.9
015 638 686 634 595 2553 015 289.5 311.3 287.4 269.9 1158.1
018 953 854 797 877 3481 018 432.1 387.3 361.5 397.9 1578.8
020 955 856 799 879 3489 020 433.0 388.3 362.4 398.8 1582.4
025 982 880 825 910 3598 025 445.6 399.2 374.2 412.9 1631.9
030 994 890 834 921 3639 030 450.9 403.8 378.2 417.6 1650.4
035 1830 1905 1589 1544 6868 035 830.2 863.9 720.9 700.2 3115.1
040 1881 1874 1565 1570 6890 040 853.3 849.8 709.9 712.1 3125.1
045 1854 1933 1602 1554 6943 045 840.9 876.9 726.6 704.8 3149.1
050 1909 1900 1576 1582 6967 050 866.1 861.9 714.9 717.4 3160.3
055 1921 1938 1612 1602 7074 055 871.5 878.9 731.4 726.9 3208.6
060 1924 1938 1613 1605 7080 060 872.5 879.1 731.9 727.8 3211.3
30RAP
SIZE
POUNDS
30RAP
SIZE
KILOGRAMS
A B C D
Total
Weight
A B C D
Total
Weight
010 661 737 684 620 2702 010 299.7 334.5 310.2 281.2 1225.6
015 665 741 686 623 2716 015 301.8 336.3 311.2 282.5 1231.8
018 993 895 836 918 3643 018 450.6 406.1 379.4 416.4 1652.5
020 995 897 838 920 3651 020 451.6 407.0 380.3 417.3 1656.1
025 1023 921 865 951 3760 025 464.2 417.9 392.2 431.4 1705.6
030 1035 931 873 961 3801 030 469.5 422.5 396.1 436.0 1724.1
035 1918 1990 1675 1629 7211 035 870.0 902.5 759.8 738.7 3271.0
040 1968 1959 1650 1656 7233 040 892.7 888.8 748.5 751.0 3281.0
045 1942 2018 1688 1639 7286 045 880.7 915.4 765.6 743.3 3305.0
050 1996 1986 1661 1668 7311 050 905.5 900.9 753.4 756.4 3316.2
055 2008 2023 1698 1688 7417 055 911.0 917.7 770.1 765.7 3364.5
060 2011 2024 1699 1690 7423 060 912.0 917.9 770.5 766.7 3367.2
B
A
C
D
CONTROL
BOX
SIDE
30RAP010-030 Units
30RAP035-060 Units
NOTE: Even with the storage tank, all
30RAP chillers require only 4-point
support. All weights include water.
