4
SEE DETAIL A
Ø2-1/2 IN. VICTAULIC WATER INLET/OUTLET
A
CHILLER MOUNTING SLOT
TANK
ACCESS
TANK
ACCESS
TANK
ACCESS
TANK
ACCESS
CHILLER WATER IN (REF)
TANK ACCESS
2' 8-13/32"
[823]
2' 47/64"
[628]
9-25/32"
[248]
5-3/4"
[146]
5' 6-15/16"
[1700]
TANK ACCESS
CHILLER WATER OUT (REF)
CONTROL
BOX END
1' 10-7/8"
[581]
2 X 12.03
[305.64]
SECTION A-A
2 PLCS
2 X 12.03
[305.66]
2 X 7.03
[178.68]
2 X 14.07
[357.25]
1/4" VENT
2 PLCS
2" SQ DRAIN
2 PLCS
3" [76.2]
MOUNTING HOLES,
FOUR CORNERS (TYP)
Ø .395/.405 (TYP)
MOUNTING HOLES
MIDDLE EACH SIDE
2' 9-15/32" [850]
CENTER OF GRAVITY
A
1' 5-13/32"
[442]
Ø2-1/2" VICTAULIC WATER
INLET/OUTLET
2 X 4-7/8"
[124]
2 X 1-1/16"
[27]
1' 1/32"
[306]
1' 1/32"
[306]
1' 5-13/32"
[442]
1' 11-1/2" [597]
CENTER OF GRAVITY
DETAIL A
AT (4) PLCS
Ø7/16" [11] X 1" [25] LG SLOT
2 X 1" [25]
CONTROL
BOX END
.88" [22.35]Ø KNOCKOUT
FOR POWER TO CONTROL BOX
TANK
ACCESS
TANK
ACCESS
TANK
ACCESS
2 X 3' 1-1/4" [946]
CHILLER MOUNTING SLOT
C.B.
ACCESS
3' 10-63/64"
[1193]
1-1/2"
[38.1]
Fig. 3 — Dimensions 30RA-900---050 (Unit Sizes 010,015)
NOTE: Dimensions are in inches [mm].
