Carrier 30WG User Manual

21
7.2 - Conguration menu
Icon Displayed text* Description Associated table
Genunit Cong General conguration GENCONF
Pump Conguration Pump conguration PUMPCONF
Heat/Cool Cong Heat/Cool conguration HCCONFIG
HDC Conguration Heating Device Control conguration HDC_CONF
Reset Cong Reset conguration RESETCFG
User Conguration User conguration USERCONF
Schedule Schedule menu SCHEDULE
Holiday Holiday menu HOLIDAY
Broadcast Broadcast conguration BROCASTS
Date/Time Date/time conguration DATETIME
Control Identication Control identication CTRL_ID
*Depends on the selected language (English by default).
CAUTION: Since specic units may not include additional features, some tables may contain parameters that cannot be
congured for a given unit.
Genunit Cong Menu – GENCONF
No. Point name Status Default Unit Displayed text* Description
1 lead_cir 0 to 2 0 - Cir Priority Sequence Circuit priority
2 0=Auto 1=A Lead 2=B Lead 0 = Automatic circuit selection
1 = Circuit A priority
2 = Circuit B priority
3 seq_typ no / yes no - Staged Loading Sequence Staged loading sequence
4 ramp_sel no / yes no - Ramp Loading Select Ramp loading selection
5 o_on_d 1 to 15 1 min Unit O to On Delay Unit O to On delay
6 nh_limit 0 to 100 100 % Night Capacity Limit Night capacity limit
7 nh_start 00:00 00:00 - Night Mode Start Hour Night mode start hour
8 nh_end 00:00 00:00 - Night Mode End Hour Night mode end hour
*Depends on the selected language (English by default).
Pump Conguration Menu – PUMPCONF
No. Point name Status Default Unit Displayed text* Description
1 COOLER PUMP EVAPORATOR PUMP
2 clpmpseq 0 to 4 0 - Cooler Pumps Sequence Evaporator pumps sequence
3 0 = No Pump 0 = No Pump
4 1 = One Pump Only 1 = One Pump Only
