SG-38MHRC-01 Specifications subject to change without notice. 5
DIMENSIONS AND WEIGHTS
Table 5 — Dimensions and Weights
Fig. 1 — Size 12K (115V)
SYSTEM SIZE 12K (115V) 9K (208/230V) 12K (208/230V) 18K (208/230V) 24K (208/230V)
Height (H) in (mm) 21.85(555) 21.85(555) 21.85(555) 21.81(554) 26.50(673)
Width (W) in (mm) 30.12(765) 30.12(765) 30.12(765) 31.69(805) 35.04(890)
Depth (D) in (mm) 11.93(303) 11.93(303) 11.93(303) 12.99(330) 13.46(342)
Weight - Net lbs. (kg) 62.17(28.2) 55.11(25.0) 59.30(26.9) 73.85(33.5) 97.88(44.4)
Packaging
Height in (mm) 24.02(610) 24.02(610) 24.02(610) 24.21(615) 29.13(740)
Width in (mm) 34.92(887) 34.92(887) 34.92(887) 36.02(915) 39.17(995)
Depth in (mm) 13.27(337) 13.27(337) 13.27(337) 14.57(370) 15.67(398)
Weight - Gross lbs. (kg) 67.68(30.7) 60.85(27.6) 64.82(29.4) 79.81(36.2) 104.50(47.4)
Carton Material -- Carton Box
Material Thickness in (mm) 0.197(5) 0.197(5) 0.197(5) 0.197(5)
0.295(7.5)
