SG-38MHRC-01 Specifications subject to change without notice. 3
SPECIFICATIONS (HEAT PUMP)
Table 2 — Specifications (Heat Pump)
Compatibility
Table 3 — Compatibility
SYSTEM
SIZE 12K 9K 12K 18K 24K
Outdoor Model 38MHRCQ12AA1 38MHRCQ09AA3 38MHRCQ12AA3 38MHRCQ18AA3 38MHRCQ24AA3
Electrical
Voltage, Phase,
Cycle
V/Ph/Hz 115-1-60 208/230-1-60 208/230-1-60 208/230-1-60 208/230-1-60
MCA A. 18.5 12.0 15 15 19
Recommended
Fuse Size
20 15 15 20 20
MOCP - Fuse
Rating
A. 25 15 15 20 30
Operating
Range
Cooling Outdoor
DB Min - Max
° F (° C)
0~ 122
(-17~ 50)
0~ 122
(-17~ 50)
0~ 122
(-17~ 50)
0~ 122
(-17~ 50)
0~ 122
(-17~ 50)
Heating Outdoor
DB Min - Max
° F (° C)
0~ 86
(-17~ 30)
0~ 86
(-17~ 30)
0~ 86
(-17~ 30)
0~ 86
(-17~ 30)
0~ 86
(-17~ 30)
Piping
Total Piping
Length
ft (m) 82 (25) 82 (25) 82 (25) 98 (30) 164 (50)
Piping Lift
*
ft (m) 33 (10) 33 (10) 33 (10) 66 (20) 82 (25)
Pipe Connection
Size - Liquid
in (mm) 1/4 (6.35) 1/4 (6.35) 1/4 (6.35) 1/4 (6.35) 3/8 (9.52)
Pipe Connection
Size - Suction
in (mm) 1/2 (12.7) 3/8 (9.52) 1/2 (12.7) 1/2 (12.7) 5/8 (16)
Refrigerant
Type R410A R410A R410A R410A R410A
Charge lbs (kg) 1.79 (0.81) 1.59 (0.72) 1.79 (0.81) 2.98 (1.35) 3.92 (1.78)
Metering Device Capillary Capillary Capillary Capillary Capillary
Outdoor
Coil
Face Area Sq. Ft. 4.0 4.0 4.0 4.7 5.9
No. Rows 1 1 1 2 1.6
Fins per inch 20 18 20 20 20
Circuits 22245
Compressor
Type Rotary Inverter Rotary Inverter Rotary Inverter Rotary Inverter Rotary Inverter
Model KSK103D33UEZ3 KSN98D64UFZ3 KSN98D64UFZ3 KSN140D21UFZ KTM240D43UKT
Oil Type VG74 VG74 VG74 VG74 VG74
Oil Charge Fl. Oz. 10.15 10.48 10.15 14.88 20.97
Rated Current RLA 7.5 7.0 12.98 10 14.25
Outdoor
Unit Width in (mm) 30.31 (770) 30.31 (770) 30.31 (770) 31.50 (800) 33.27 (845)
Unit Height in (mm) 21.85 (555) 21.85 (555) 21.85 (555) 21.81 (554) 27.64 (702)
Unit Depth in (mm) 11.81 (300) 11.81 (300) 11.81 (300) 13.11 (333) 14.29 (363)
Net Weight lbs (kg) 69 (31.3) 63 (28.6) 65.5 (29.7) 79.6 (36.1) 114.2 (51.8)
Airflow CFM 1,170 1,170 1,170 1,170 1,765
Sound Pressure dB(A) 54.5 57.2 57.4 57.0 60.2
INDOOR UNIT 38MHRCQ12AA1 38MHRCQ09AA3 38MHRCQ12AA3 38MHRCQ18AA3 38MHRCQ24AA3
High Wall
40MHHQ12---1 ●
40MHHQ09---3 ●
40MHHQ12---3 ●
40MHHQ18---3 ●
40MHHQ24---3 ●
