6
OUTDOOR UNITS
*Based on approximately 25 ft of interconnecting piping. Unit supplied with factory holding charge.
Charge unit per charging chart located on unit.
†Equipped with one electric unloader
**With condenser 80% full of liquid at 120 F.
UNIT 38AQS 008 012 016
NOMINAL CAPACITY (tons)
7
1
/
2
10 15
OPERATING WT (lb)
546 750 803
REFRIGERANT (R-22)
Operating Charge (lb)*
19.5 30 37
COMPRESSOR
06DA818 06DF824† 06DF537†
Cylinders
466
Rpm
1750
Oil Charge (pt) (ea)
5.5 8.0 8.0
OUTDOOR FANS
Propeller; Direct Drive
Qty
12
Rpm
1100 1075
Blade Diameter (in.)
26 26
Motor Hp
3
/
4
1
/
2
Cfm
6500 11,000
kW
0.96 1.46
OUTDOOR COIL
No. of Rows...Fins/in.
2...17 2...15 3...15
Face Area (sq ft)
18.0 29.2 29.2
Storage Capacity (lb)**
16.6 27.2 40.1
CONNECTIONS (Sweat)
Suction (in.)
1
1
/
8
1
1
/
8
1
3
/
8
Liquid (in.)
1
/
2
5
/
8
5
/
8
CONTROLS
Pressurestat Settings (psig)
High Cutout
426 ± 7 400 400
Cut-in
320 ± 20 300 300
Low Cutout
7 ± 3 7 ± 3 7 ± 3
Cut-in
22 ± 5 22 ± 5 22 ± 5
Defrost Thermostat
Initiate Defrost (F)
28 27 27
Terminates Defrost (F)
65 65 80
Physical data
WEIGHT DISTRIBUTION
LEGEND
C —
Optional coil with copper fins
UNIT
38AQS
OPERATING
WEIGHT
(Total)
WEIGHT (lb)
Leg Location
1234
008
546 175 133 132 100
008C
608 189 160 142 117
012
750 147 228 228 147
012C
845 166 266 242 171
016
803 158 243 244 158
016C
944 186 299 265 194
