Table 6—Maximum Allowable Pipe Length (Ft) Continued
ALTITUDE
UNIT
SIZE
TERMINATION
TYPE
PIPE DIAMETER
(IN.)*
NUMBER OF 90° ELBOWS
12345 6
6001 to 7000‡
040-14
2 Pipe or 2-In.
Concentric
1-1/2 35 30 25 20 15 10
2 7070686766 64
060-14
2 Pipe or 2-In.
Concentric
1-1/2 35 30 25 20 15 10
2 7070686766 64
080-14
080-20
2 Pipe or 2-In.
Concentric
1-1/2 20 15 10 5 NA NA
2 7070686762 57
100-20
2 Pipe or 2-In.
Concentric
2 3126211611 6
2-1/2 70 70 68 67 66 64
120-20
2 Pipe or 3-In.
Concentric
3† 49 48 47 45 44 43
ALTITUDE
UNIT
SIZE
TERMINATION
TYPE
PIPE DIAMETER
(IN.)*
NUMBER OF 90° ELBOWS
1234 5 6
7001 to 8000‡
040-14
2 Pipe or 2-In.
Concentric
1-1/2 32 27 22 17 12 7
2 66656362 60 59
060-14
2 Pipe or 2-In.
Concentric
1-1/2 32 27 22 17 12 7
2 66656362 60 59
080-14
080-20
2 Pipe or 2-In.
Concentric
1-1/2 18 13 8 NA NA NA
2 66656362 57 52
100-20
2 Pipe or 2-In.
Concentric
2 29241914 9 NA
2-1/2 66 65 63 62 60 59
120-20
2 Pipe or 3-In.
Concentric
3† 46 44 43 41 40 38
ALTITUDE
UNIT
SIZE
TERMINATION
TYPE
PIPE DIAMETER
(IN.)*
NUMBER OF 90° ELBOWS
1234 5 6
8001 to 9000‡
040-14
2 Pipe or 2-In.
Concentric
1-1/2 30 25 20 15 10 5
2 62605856 55 53
060-14
2 Pipe or 2-In.
Concentric
1-1/2 30 25 20 15 10 5
2 62605856 55 53
080-14
080-20
2 Pipe or 2-In.
Concentric
1-1/2 17 12 7 NA NA NA
2 62605856 51 46
100-20
2 Pipe or 2-In.
Concentric
2 27221712 7 NA
2-1/2 62 60 58 56 55 53
120-20
2 Pipe or 3-In.
Concentric
3† 43 41 39 37 35 34
ALTITUDE
UNIT
SIZE
TERMINATION
TYPE
PIPE DIAMETER
(IN.)*
NUMBER OF 90° ELBOWS
1234 5 6
9001 to 10000‡
040-14
2 Pipe or 2-In.
Concentric
1-1/2 27 22 17 12 7 NA
2 57555351 49 47
060-14
2 Pipe or 2-In.
Concentric
1-1/2 27 22 17 12 7 NA
2 57555351 49 47
080-14
080-20
2 Pipe or 2-In.
Concentric
1-1/2 15 10 5 NA NA NA
2 57555351 46 41
100-20
2 Pipe or 2-In.
Concentric
2 241914 9 NANA
2-1/2 57 55 53 51 49 47
120-20
2 Pipe or 3-In.
Concentric
3† 39 37 35 33 31 29
* Disk usage—Unless otherwise stated, use perforated disk assembly (factory-supplied in loose parts bag).
† Wide radius elbow.
‡ Vent sizing for Canadian installations over 4500 ft (1370m) above sea level are subject to acceptance by the local authorities having jurisdiction.
NA—Not Allowed; pressure switch will not make.
NOTES:
1. Do not use pipe size greater than those specified in table or incomplete combustion, flame disturbance, or flame sense lockout may occur.
2. Size both the combustion-air and vent pipe independently, then use the larger diameter for both pipes.
3. Assume two 45° elbows equal one 90° elbow. Long radius elbows are desirable and may be required in some cases.
4. Elbows and pipe sections within the furnace casing and at the vent termination should not be included in vent length or elbow count.
5. The minimum pipe length is 5 ft for all applications.
27
