30RA – Air-Cooled AquaSnap Chiller
Refrigerant Type
P – Puron
Revision Level
A – Current Revision Level
Unit Sizes
010 025 045 070
015 030 050 080
018 035 055 090
020 040 060
Vol tage
1 – 575-3-60
2 – 380-3-60
5 – 208/230-3-60
6 – 460-3-60
Condenser Coil/Low Sound Options
5 – MCHX, Value Sound Fan
6 – MCHX, E-coat, Value Sound Fan
D – MCHX, AeroAcoustic™ Fan
F – MCHX, E-coat, AeroAcoustic Fan
J – MCHX, AeroAcoustic Fan, Compressor Blanket(s)
K – MCHX, E-coat, AeroAcoustic Fan, Compressor Blanket(s)
Hydronic System
30RAP010-060
0 – No Pump
2 – Single Pump, 1.5 Hp
3 – Single Pump, 3 Hp
4 – Single Pump, 3 Hp High Head
5 – Single Pump, 5 Hp
6 – Single Pump, 5 Hp High Head
7 – Single Pump, 7.5 Hp
Z – Single Pump, 10 Hp
9 – Dual Pump, 1.5 Hp
B – Dual Pump, 3 Hp
C – Dual Pump, 3 Hp High Head
D – Dual Pump, 5 Hp
F – Dual Pump, 5 Hp High Head
G – Dual Pump, 7.5 Hp
H – Dua l Pump, 10 Hp
Ambient/Capacity Control/Interrupt Options
0 – Std Comp, Std Interrupt
1 – Hot Gas Bypass, Std Interrupt
2 – Digital Comp, Std Interrupt
3 – Std Comp, High Interrupt
4 – Hot Gas Bypass, High Interrupt
5 – Digital Comp, High Interrupt
6 – Low Ambient, Std Comp, Std Interrupt
7 – Low Ambient, Hot Gas Bypass, Std Interrupt
8 – Low Ambient, Digital Comp, Std Interrupt
9 – Low Ambient, Std Comp, High Interrupt
B – Low Ambient, Hot Gas Bypass, High Interrupt
C – Low Ambient, Digital Comp, High Interrupt
D – Std Comp, Std Interrupt, Suction Service Valve
F – Hot Gas Bypass, Std Interrupt, Suction Service Valve
G – Digital Comp, Std Interrupt, Suction Service Valve
H – Std Comp, High Interrupt, Suction Service Valve
J – Hot Gas Bypass, High Interrupt, Suction Service Valve
K – Digital Comp, High Interrupt, Suction Service Valve
L – Low Ambient, Std Comp, Std Interrupt, Suction Service Valves
M – Low Ambient, Hot Gas Bypass, Std Interrupt, Suction Service Valves
N – Low Ambient, Digital Comp, Std Interrupt, Suction Service Valves
P – Low Ambient, Std Comp, High Interrupt, Suction Service Valves
Q – Low Ambient, Hot Gas Bypass, High Interrupt, Suction Service Valves
R – Low Ambient, Digital Comp, High Interrupt, Suction Service Valves
Electrical Options
30RAP010-060
0 – No Disconnect, No Cooler Heater
1 – No Disconnect, Cooler Heater
D – Non-Fused Disconnect, No Cooler Heater
F – Non-Fused Disconnect, Cooler Heater
Controls/Communications Options
0 – Std
1 – Std, BACnet Communication
5 – EMM
6 – EMM, BACnet Communication
B – EMM, GFI
C – EMM, GFI, BACnet Communication
H – GFI
J – GFI,
BACnet Communication
Packaging/Security Options
0 – Std Packaging
4 – Security Grilles/Hail Guards Only
8 – Skid Only
D – Skid, Security Grilles/Hail Guards
J – Skid, Top Crate, Bag
N – Skid, Top Crate, Bag, Security Grilles/Hail Guards
®
30RAP070-090
0 – No Pump
1 – Single Pump, 3 Hp
2 – Single Pump, 5 Hp
3 – Single Pump, 7.5 Hp
4 – Single Pump, 10 Hp
5 – Single Pump, 15 Hp
6 – Dual Pump, 3 Hp
7 – Dual Pump, 5 Hp
8 – Dual Pump, 7.5 Hp
9 – Dual Pump, 10 Hp
B – Dual Pump, 15 Hp
C – Single Pump, 3 Hp with VFD
D – Single Pump, 5 Hp with VFD
F – Single Pump, 7.5 Hp with VFD
G – Single Pump, 10 Hp with VFD
H – Single Pump, 15 Hp with VFD
J – Dual Pump, 3 Hp with VFD
K – Dual Pump, 5 Hp with VFD
L – Dual Pump, 7.5 Hp with VFD
M – Dual Pump, 10 Hp with VFD
N – Dual Pump, 15 Hp with VFD
30RAP070-090
0 – Single Point, No Disconnect, No Cooler Heater
1 – Single Point, No Disconnect, Cooler Heater
2 – Single Point, Non-Fused Disconnect, No Cooler Heater
3 – Single Point, Non-Fused Disconnect, Cooler Heater
4 – Dual Point, No Disconnect, No Cooler Heater
5 – Dual Point, No Disconnect, Cooler Heater
AQUASNAP
®
CHILLER MODEL NUMBER DESIGNATION
LEGEND
EMM — Energy Management Module
GFI — Ground Fault Interrupting
MCHX — Microchannel Heat Exchanger
SCCR — Short Circuit Current Rating
Quality Assurance
Certified to ISO 9001
a30-5348
Model number nomenclature
