Carrier Aquasnap 30RAP050 User Manual

45
30RAP ELECTRICAL DATA
SINGLE POINT NO HYDRONIC PACKAGE
LEGEND
NOTES:
1. Units are suitable for use on electrical systems where voltage supplied to the unit terminals
is not below or above the listed minimum and maximum limits. Maximum allowable phase
imbalance is: voltage, 2%; amps 10%.
2. All units/modules have single point primary power connection. (Each unit/module requires
its own power supply.) Main power must be supplied from a field-supplied disconnect.
3. Cooler heater is wired into the control circuit so it is always operable as long as the power
supply disconnect is on, even if any safety device is open.
4. Power draw control circuits include cooler heaters (where used).
UNIT
30RAP
UNIT VOLTAGE
POWER
SUPPLY
QTY
REQD.
NO HYDRONIC PACKAGE
STANDARD LOW-SOUND AEROACOUSTIC™ FAN
NO HYDRONIC PACKAGE
OPTIONAL VALUE SOUND FANS
V-Hz
(3 Ph)
Supplied
MCA MOCP ICF
Rec
Fuse
Size
MCA MOCP ICF
Rec
Fuse
Size
Min Max
010
208/230-60 187 253 1 66.1 110 251.0 80 66.7 110 251.6 80
380-60 342 418 1 33.5 50 148.9 40 33.5 50 148.9 40
460-60 414 506 1 26.2 40 127.9 35 26.6 45 128.3 35
575-60 518 633 1 20.8 35 102.4 25 21.0 35 102.6 25
015
208/230-60 187 253 1 75.8 125 346.0 90 76.4 125 346.6 100
380-60 342 418 1 46.4 80 199.9 60 46.4 80 199.9 60
460-60 414 506 1 36.5 60 181.9 45 36.9 60 182.3 45
575-60 518 633 1 32.0 50 134.4 40 32.2 50 134.6 40
018
208/230-60 187 253 1 87.2 110 270.4 100 88.4 110 271.6 100
380-60 342 418 1 51.1 70 167.0 60 51.1 70 167.0 60
460-60 414 506 1 43.4 60 136.5 50 44.2 60 137.3 50
575-60 518 633 1 34.9 45 98.2 40 35.3 45 98.6 40
020
208/230-60 187 253 1 92.6 125 286.8 110 93.8 125 288.0 110
380-60 342 418 1 61.2 80 176.5 70 61.2 80 176.5 70
460-60 414 506 1 46.1 60 148.7 60 46.9 60 149.5 60
575-60 518 633 1 37.0 50 99.1 45 37.4 50 99.5 45
025
208/230-60 187 253 1 127.4 175 363.3 150 128.6 175 364.5 150
380-60 342 418 1 68.3 90 173.7 80 68.3 90 173.7 80
460-60 414 506 1 57.8 80 178.9 70 58.6 80 179.7 70
575-60 518 633 1 49.6 60 133.7 60 50.0 60 134.1 60
030
208/230-60 187 253 1 137.6 175 407.8 175 138.8 175 409.0 175
380-60 342 418 1 84.3 110 237.8 100 84.3 110 237.8 100
460-60 414 506 1 66.3 90 211.7 80 67.1 90 212.5 80
575-60 518 633 1 58.1 80 160.5 70 58.5 80 160.9 70
035
208/230-60 187 253 1 165.4 200 359.6 175 167.2 200 361.4 200
380-60 342 418 1 103.5 125 218.9 110 103.5 125 218.9 110
460-60 414 506 1 82.4 100 185.0 90 83.6 100 186.2 90
575-60 518 633 1 66.1 80 128.2 70 66.7 80 128.8 80
040
208/230-60 187 253 1 197.8 225 395.0 225 199.6 225 396.8 225
380-60 342 418 1 112.5 125 227.8 125 112.5 125 227.8 125
460-60 414 506 1 86.4 100 188.8 100 87.6 100 190.0 100
575-60 518 633 1 68.9 80 150.9 80 69.5 80 151.5 80
045
208/230-60 187 253 1 229.6 250 468.7 250 231.4 250 470.5 250
380-60 342 418 1 119.6 125 228.2 125 119.6 125 228.8 125
460-60 414 506 1 97.9 110 223.5 110 99.1 110 224.7 110
575-60 518 633 1 81.4 100 170.7 90 82.0 100 171.3 90
050
208/230-60 187 253 1 236.0 250 471.9 250 237.8 250 473.7 250
380-60 342 418 1 126.0 150 231.4 150 126.0 150 231.4 150
460-60 414 506 1 106.9 125 228.0 125 108.1 125 229.2 125
575-60 518 633 1 91.8 110 175.9 100 92.4 110 176.5 100
055
208/230-60 187 253 1 252.2 300 526.9 300 254.6 300 529.3 300
380-60 342 418 1 145.9 175 306.5 175 145.9 175 306.5 175
460-60 414 506 1 118.3 125 267.5 125 119.9 125 269.1 125
575-60 518 633 1 102.7 125 208.9 110 103.5 125 209.7 110
060
208/230-60 187 253 1 261.2 300 531.4 300 263.6 300 533.8 300
380-60 342 418 1 160.1 175 313.6 175 160.1 175 313.6 175
460-60 414 506 1 125.9 150 271.3 150 127.5 150 272.9 150
575-60 518 633 1 110.3 125 212.7 125 111.1 125 213.5 125
070
208/230-60 187 253 1 323.0 350 593.2 350 326.0 350 596.2 350
380-60 342 418 1 198.0 225 351.5 225 198.0 225 351.5 225
460-60 414 506 1 155.7 175 301.1 175 157.7 175 303.1 175
575-60 518 633 1 136.4 150 238.8 150 137.4 150 239.8 150
080
208/230-60 187 253 1 371.3 400 641.5 400 374.9 400 645.1 400
380-60 342 418 1 214.6 225 368.1 225 214.6 225 368.1 225
460-60 414 506 1 174.1 200 319.5 200 176.5 200 321.9 200
575-60 518 633 1 151.1 175 253.5 175 152.3 175 254.7 175
090
208/230-60 187 253 1 384.8 400 655.0 400 388.4 400 658.6 400
380-60 342 418 1 235.9 250 389.4 250 235.9 250 389.4 250
460-60 414 506 1 185.5 200 330.9 200 187.9 200 333.3 200
575-60 518 633 1 162.5 175 264.9 175 163.7 175 266.1 175
ICF — Instantaneous Current Flow
MCA — Minimum Circuit Amps
MOCP — Maximum Overcurrent Protection
Electrical data
