LEGEND * Air Conditioning, Heating, and Refrigeration Institute.
NOTE: Based on AHRI-550/590 standard rating conditions. Ratings are for
standard chillers only. Ratings do not include options.
UNIT
30RAP
CAPACITY
COMPRESSOR
POWER INPUT
(kW)
FAN
POWER
(kW)
TOTAL
POWER
(kW)
FULL LOAD IPLV
COOLER FLOW
RATE
COOLER
WATER
PRESSURE
DROP
Tons kW EER COP EER COP GPM L/s Ft wg kPa
010 10.5 36.8 10.7 1.2 12.0 10.5 3.1 14.2 4.2 25.1 1.6 13.7 40.9
015 14.0 49.2 15.6 1.3 16.8 10.0 2.9 13.2 3.9 33.5 2.1 15.7 46.8
018 16.1 56.6 15.6 3.0 18.6 10.4 3.0 14.5 4.2 38.6 2.4 15.6 46.5
020 18.8 66.1 19.1 2.9 21.9 10.3 3.0 14.5 4.2 45.2 2.9 14.2 42.4
025 23.4 82.3 24.5 2.8 27.4 10.3 3.0 15.3 4.5 56.3 3.6 17.8 53.1
030 27.6 97.1 30.9 2.7 33.6 9.9 2.9 14.8 4.3 66.3 4.2 20.9 62.3
035 34.4 121.0 35.9 3.8 39.7 10.4 3.0 14.9 4.4 82.5 5.2 13.2 39.4
040 38.9 136.8 42.3 3.8 46.1 10.1 3.0 15.3 4.5 93.4 5.9 13.8 41.2
045 43.1 151.6 48.6 3.4 52.0 10.0 2.9 15.3 4.5 103.4 6.5 15.3 45.6
050 47.3 166.3 53.1 3.8 57.0 10.0 2.9 14.7 4.3 113.5 7.2 19.1 57.0
055 51.8 182.2 56.4 5.3 61.7 10.1 3.0 14.6 4.3 124.2 7.8 17.6 52.5
060 56.0 196.9 60.8 5.3 66.2 10.2 3.0 14.5 4.2 134.4 8.5 20.5 61.2
070 68.9 242.3 74.6 6.8 81.4 10.2 3.0 15.2 4.5 165.2 10.4 19.5 59.4
080 77.4 272.2 83.2 6.7 89.9 10.3 3.0 15.5 4.5 185.9 11.7 21.2 52.5
090 84.0 295.4 91.0 6.8 97.8 10.3 3.0 15.9 4.7 201.7 12.7 22.7 65.6
COP — Coefficient of Performance
EER — Energy Efficiency Ratio
IPLV — Integrated Part Load Value
AHRI* capacity ratings
