6.14 - Web connection
The Touch Pilot control can be accessed via a web browser
(Internet Explorer, Mozilla Firefox, etc.).
Connection is from a PC using a web browser with Java.
CAUTION: Use rewalls and VPN for secure connection.
6.14.1 - Web interface
To access the control, provide the IP address of the unit in the
address bar of the web browser.
Legend
1. Technical documentation button
2. Help button
Unit default address: 169.254.0.1. This address can be changed.
IMPORTANT: Only two web connections can be authorised
at the same time.
6.14.2 - Web browser settings
Minimum web browser conguration:
- Internet Explorer (version 8 or higher) or Mozilla Firefox
(version 26 or higher). In the advanced connection options
add the unit IP address to the exceptions list. Do not use a
proxy server.
- Java platform (version 6 or higher). In the control panel, clear
the Keep temporary les on my computer check box and use
a direct connection.
IMPORTANT: Two users can be connected simultaneously
with no priority between them.
Note that the last modication is always taken into account.
6.14.3 - Technical documentation
When the Touch Pilot control is used via a pc web browser,
the controller allows the user to access the technical documentation
for the product.
■ Once you connect to the Touch Pilot control, click the Technical
documentation button in order to see a list of documents related
to the unit.
Technical documentation includes the following documents:
- Spare parts documentation: The list of spare parts included
in the unit with reference, description and drafting.
- Misc: Documents such as electrical plans, dimension plans,
unit certicates.
- PED: Pressure Equipment Directive.
- IOM: Installation operation and maintenance manual, controls
installation/maintenance manual.
■ Click the Help button to get access to BACnet user guide.
B
C
6 - SETTING UP TOUCH PILOT CONTROL
15
